Product Description
With a working weight of 3336.2 kg and a bucket capacity of 0.08 m³, this 2014 Volvo ECR38 excavator is ready for immediate deployment in 四川泸州. Available now, it allows you to skip the factory lead times and get your project moving swiftly. Equipped with a traditional power Volvo D1.6 engine, delivering 20.6 kW at 2200 rpm, this compact excavator ensures reliable performance and efficient operation.
- Maximum digging depth: 2740 mm
- Travel speed: 3.9 km/h
- Total transport dimensions: 4420 x 1620 x 2440 mm (L x W x H)
- Fast deployment to your site in 四川泸州
- Backhoe bucket with a digging force of 2932 kN
| Specifications | Value |
|---|---|
| No. | 1000261 |
| Tonnage (tons) | 3 |
| Working weight (kg) | 3336.2 |
| Bucket capacity (m³) | 0.08 |
| Boom length (mm) | 2300 |
| Rod length (mm) | 1250 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Volvo Volvo D1.6 |
| Rated power (kw/rpm) | 20.6/2200 |
| Number of cylinders (PCS) | 3 |
| Displacement (L) | 1.6 L |
| Ground specific pressure (Kpa) | 30.3 |
| Rotation speed (rpm) | 10 |
| Bucket digging force (kN) | 2932 |
| Rod digging force (kN) | 1953 |
| Travel speed (km/h) | 3.9 |
| Maximum flow of main pump (l/min) | 94.3 |
| Fuel Tank (L) | 49 |
| Engine Oil changes (L) | 7 |
| Coolant (L) | 5 |
| Hydraulic System (L) | 48 |
| Total transport length (mm) | 4420 |
| Total transport width (mm) | 1620 |
| Total transport height (mm) | 2440 |
| Full cab height (mm) | 2440 |
| Counterweight ground clearance (mm) | 580 |
| Minimum ground clearance (mm) | 290 |
| Back end turning radius (mm) | 810 |
| Track gauge (mm) | 1320 |
| Track plate width (mm) | 300 |
| Track ground length (mm) | 1600 |
| Maximum digging depth (mm) | 2740 |
| Maximum excavation height (mm) | 4430 |
| Maximum unloading height (mm) | 3190 |
| Maximum vertical digging depth (mm) | 2540 |
| Maximum excavation radius of stop surface (mm) | 4810 |
