Product Description
With a working weight of 3,336.2 kg and a bucket capacity of 0.08 m³, this 2014 Volvo ECR38 excavator, located in 贵州, is site-ready for immediate deployment. Equipped with a traditional power Volvo D1.6 engine, it delivers 20.6 kW at 2,200 rpm, ensuring reliable performance. Designed for efficient digging, grading, and demolition, the ECR38 boasts a maximum digging depth of 2,740 mm and a bucket digging force of 29.32 kN. Its compact design, featuring a total transport length of 4,420 mm and width of 1,620 mm, makes it highly maneuverable on tight job sites. The machine's robust hydraulic system, with a main pump flow of 94.3 l/min, supports versatile operations. Ready to tackle your next project, this Volvo ECR38 is a dependable choice for construction and excavation tasks.
| Specifications | Value |
|---|---|
| No. | 1000844 |
| Tonnage (tons) | 3 |
| Working weight (kg) | 3336.2 |
| Bucket capacity (m³) | 0.08 |
| Boom length (mm) | 2300 |
| Rod length (mm) | 1250 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Volvo Volvo D1.6 |
| Rated power (kw/rpm) | 20.6/2200 |
| Number of cylinders (PCS) | 3 |
| Displacement (L) | 1.6 L |
| Ground specific pressure (Kpa) | 30.3 |
| Rotation speed (rpm) | 10 |
| Bucket digging force (kN) | 2932 |
| Rod digging force (kN) | 1953 |
| Travel speed (km/h) | 3.9 |
| Maximum flow of main pump (l/min) | 94.3 |
| Fuel Tank (L) | 49 |
| Engine Oil changes (L) | 7 |
| Coolant (L) | 5 |
| Hydraulic System (L) | 48 |
| Total transport length (mm) | 4420 |
| Total transport width (mm) | 1620 |
| Total transport height (mm) | 2440 |
| Full cab height (mm) | 2440 |
| Counterweight ground clearance (mm) | 580 |
| Minimum ground clearance (mm) | 290 |
| Back end turning radius (mm) | 810 |
| Track gauge (mm) | 1320 |
| Track plate width (mm) | 300 |
| Track ground length (mm) | 1600 |
| Maximum digging depth (mm) | 2740 |
| Maximum excavation height (mm) | 4430 |
| Maximum unloading height (mm) | 3190 |
| Maximum vertical digging depth (mm) | 2540 |
| Maximum excavation radius of stop surface (mm) | 4810 |
