Product Description
Built to endure the toughest jobsite conditions, this 2016 Volvo ECR38 compact excavator demonstrates the legendary reliability that defines the Volvo brand. With over seven years of proven performance, this 3-ton workhorse continues to deliver consistent results across demanding applications. Powered by the robust Volvo D1.6 engine producing 20.6 kW at 2200 rpm, this machine combines efficient fuel consumption with dependable operation day after day.
Engineered for precision work in confined spaces, the ECR38 offers a maximum digging depth of 2740mm and an excavation radius of 4810mm, while maintaining a compact transport width of just 1620mm. The joint venture manufacturing ensures superior build quality backed by Volvo's engineering standards. Currently located in Hunan, this proven excavator features a 0.08m³ bucket capacity, 2932kN bucket digging force, and a comprehensive hydraulic system designed for longevity.
- Working weight: 3336.2 kg with exceptional stability
- Fuel tank capacity: 49L for extended operation
- Maximum excavation height: 4430mm
- Track gauge: 1320mm for superior maneuverability
- Proven traditional power system with minimal maintenance requirements
| Specifications | Value |
|---|---|
| No. | 1006083 |
| Tonnage (tons) | 3 |
| Working weight (kg) | 3336.2 |
| Bucket capacity (m³) | 0.08 |
| Boom length (mm) | 2300 |
| Rod length (mm) | 1250 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Volvo Volvo D1.6 |
| Rated power (kw/rpm) | 20.6/2200 |
| Number of cylinders (PCS) | 3 |
| Displacement (L) | 1.6 L |
| Ground specific pressure (Kpa) | 30.3 |
| Rotation speed (rpm) | 10 |
| Bucket digging force (kN) | 2932 |
| Rod digging force (kN) | 1953 |
| Travel speed (km/h) | 3.9 |
| Maximum flow of main pump (l/min) | 94.3 |
| Fuel Tank (L) | 49 |
| Engine Oil changes (L) | 7 |
| Coolant (L) | 5 |
| Hydraulic System (L) | 48 |
| Total transport length (mm) | 4420 |
| Total transport width (mm) | 1620 |
| Total transport height (mm) | 2440 |
| Full cab height (mm) | 2440 |
| Counterweight ground clearance (mm) | 580 |
| Minimum ground clearance (mm) | 290 |
| Back end turning radius (mm) | 810 |
| Track gauge (mm) | 1320 |
| Track plate width (mm) | 300 |
| Track ground length (mm) | 1600 |
| Maximum digging depth (mm) | 2740 |
| Maximum excavation height (mm) | 4430 |
| Maximum unloading height (mm) | 3190 |
| Maximum vertical digging depth (mm) | 2540 |
| Maximum excavation radius of stop surface (mm) | 4810 |
