Product Description
Built for precision work in tight quarters, this 2017 Volvo ECR38 mini excavator delivers 20.6 kW of Volvo D1.6 power across confined job sites. With a compact 1620mm transport width and 810mm rear swing radius, maneuver through narrow alleys, interior demolition zones, and urban utility installations without repositioning. The 2740mm maximum digging depth and 4810mm excavation radius handle foundation trenching, drainage systems, and landscaping cuts with authority.
- 3-ton working weight: stable operation without surface damage
- 2932 kN bucket digging force: cut through compacted soil and clay
- 0.08m³ bucket capacity: optimized for precise grading and trenching
- 94.3 L/min hydraulic flow: responsive control for detailed work
- 2440mm full cab height: operator comfort during extended shifts
- 49L fuel tank: minimize refueling downtime on active sites
Currently located in Hunan, this machine arrives ready for immediate deployment. Load, transport, and start digging the same day. Contact Fair Trade Machinery for shipping quotes and specifications.
| Specifications | Value |
|---|---|
| No. | 1017871 |
| Tonnage (tons) | 3 |
| Working weight (kg) | 3336.2 |
| Bucket capacity (m³) | 0.08 |
| Boom length (mm) | 2300 |
| Rod length (mm) | 1250 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Volvo Volvo D1.6 |
| Rated power (kw/rpm) | 20.6/2200 |
| Number of cylinders (PCS) | 3 |
| Displacement (L) | 1.6 L |
| Ground specific pressure (Kpa) | 30.3 |
| Rotation speed (rpm) | 10 |
| Bucket digging force (kN) | 2932 |
| Rod digging force (kN) | 1953 |
| Travel speed (km/h) | 3.9 |
| Maximum flow of main pump (l/min) | 94.3 |
| Fuel Tank (L) | 49 |
| Engine Oil changes (L) | 7 |
| Coolant (L) | 5 |
| Hydraulic System (L) | 48 |
| Total transport length (mm) | 4420 |
| Total transport width (mm) | 1620 |
| Total transport height (mm) | 2440 |
| Full cab height (mm) | 2440 |
| Counterweight ground clearance (mm) | 580 |
| Minimum ground clearance (mm) | 290 |
| Back end turning radius (mm) | 810 |
| Track gauge (mm) | 1320 |
| Track plate width (mm) | 300 |
| Track ground length (mm) | 1600 |
| Maximum digging depth (mm) | 2740 |
| Maximum excavation height (mm) | 4430 |
| Maximum unloading height (mm) | 3190 |
| Maximum vertical digging depth (mm) | 2540 |
| Maximum excavation radius of stop surface (mm) | 4810 |
