Product Description
Built on Volvo's proven engineering foundation, this 2017 ECR38 compact excavator delivers the reliability contractors demand in the used equipment market. Operating at 3 tons with a 3,336 kg working weight, this machine combines the precision of a 0.08 m³ bucket capacity with the backing of one of construction's most trusted names. Located in Jiangsu Changzhou, this unit features Volvo's D1.6 engine producing 20.6 kW at 2200 rpm, ensuring consistent performance across demanding jobsites.
Choosing Volvo in the pre-owned market means investing in long-term value. Parts availability remains exceptional through established dealer networks, minimizing downtime and repair costs. Strong resale values protect your capital investment, while the brand's reputation for durability translates to lower total cost of ownership.
- Maximum digging depth: 2,740 mm with 4,810 mm excavation radius
- Compact footprint: 4,420 mm transport length, 1,620 mm width
- Efficient hydraulics: 94.3 L/min main pump flow
- Proven powertrain: 3-cylinder Volvo engine with 1.6 L displacement
- Reliable support: Joint venture/import manufacturer backing
| Specifications | Value |
|---|---|
| No. | 997244 |
| Tonnage (tons) | 3 |
| Working weight (kg) | 3336.2 |
| Bucket capacity (m³) | 0.08 |
| Boom length (mm) | 2300 |
| Rod length (mm) | 1250 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Volvo Volvo D1.6 |
| Rated power (kw/rpm) | 20.6/2200 |
| Number of cylinders (PCS) | 3 |
| Displacement (L) | 1.6 L |
| Ground specific pressure (Kpa) | 30.3 |
| Rotation speed (rpm) | 10 |
| Bucket digging force (kN) | 2932 |
| Rod digging force (kN) | 1953 |
| Travel speed (km/h) | 3.9 |
| Maximum flow of main pump (l/min) | 94.3 |
| Fuel Tank (L) | 49 |
| Engine Oil changes (L) | 7 |
| Coolant (L) | 5 |
| Hydraulic System (L) | 48 |
| Total transport length (mm) | 4420 |
| Total transport width (mm) | 1620 |
| Total transport height (mm) | 2440 |
| Full cab height (mm) | 2440 |
| Counterweight ground clearance (mm) | 580 |
| Minimum ground clearance (mm) | 290 |
| Back end turning radius (mm) | 810 |
| Track gauge (mm) | 1320 |
| Track plate width (mm) | 300 |
| Track ground length (mm) | 1600 |
| Maximum digging depth (mm) | 2740 |
| Maximum excavation height (mm) | 4430 |
| Maximum unloading height (mm) | 3190 |
| Maximum vertical digging depth (mm) | 2540 |
| Maximum excavation radius of stop surface (mm) | 4810 |
