Product Description
Expand your operational capacity with this 2018 Volvo ECR38 compact excavator, currently located in Shaoxing, Zhejiang. Engineered for contractors requiring dependable backup power or fleet expansion, this 3-ton mini excavator delivers Volvo's legendary build quality in a compact footprint. Powered by a 20.6 kW Volvo D1.6 three-cylinder engine, it provides consistent performance across demanding jobsites without sacrificing fuel efficiency from its 49-liter tank.
Key specifications include:
- Operating weight: 3,336 kg with 0.08 m³ bucket capacity
- Maximum digging depth: 2,740 mm; reach: 4,810 mm
- Compact transport dimensions: 4,420 mm (L) × 1,620 mm (W) × 2,440 mm (H)
- Bucket digging force: 29.32 kN; arm force: 19.53 kN
- 810 mm zero tail swing radius for confined spaces
- 94.3 L/min hydraulic flow for responsive cycle times
Perfect for utility work, landscaping, or urban construction, this unit integrates seamlessly into existing fleets. Factory-fitted with genuine Volvo components, it maintains parts compatibility across your equipment lineup while minimizing downtime during peak scheduling periods.
| Specifications | Value |
|---|---|
| No. | 1014922 |
| Tonnage (tons) | 3 |
| Working weight (kg) | 3336.2 |
| Bucket capacity (m³) | 0.08 |
| Boom length (mm) | 2300 |
| Rod length (mm) | 1250 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Volvo Volvo D1.6 |
| Rated power (kw/rpm) | 20.6/2200 |
| Number of cylinders (PCS) | 3 |
| Displacement (L) | 1.6 L |
| Ground specific pressure (Kpa) | 30.3 |
| Rotation speed (rpm) | 10 |
| Bucket digging force (kN) | 2932 |
| Rod digging force (kN) | 1953 |
| Travel speed (km/h) | 3.9 |
| Maximum flow of main pump (l/min) | 94.3 |
| Fuel Tank (L) | 49 |
| Engine Oil changes (L) | 7 |
| Coolant (L) | 5 |
| Hydraulic System (L) | 48 |
| Total transport length (mm) | 4420 |
| Total transport width (mm) | 1620 |
| Total transport height (mm) | 2440 |
| Full cab height (mm) | 2440 |
| Counterweight ground clearance (mm) | 580 |
| Minimum ground clearance (mm) | 290 |
| Back end turning radius (mm) | 810 |
| Track gauge (mm) | 1320 |
| Track plate width (mm) | 300 |
| Track ground length (mm) | 1600 |
| Maximum digging depth (mm) | 2740 |
| Maximum excavation height (mm) | 4430 |
| Maximum unloading height (mm) | 3190 |
| Maximum vertical digging depth (mm) | 2540 |
| Maximum excavation radius of stop surface (mm) | 4810 |
