Product Description
Engineered for precision and all-day productivity, this 2014 Volvo EW50 wheeled excavator delivers exceptional maneuverability in confined urban jobsites and utility work. Operating at 5 tons with a 33.7 kW Volvo engine, this compact machine combines responsive hydraulic controls with proven stability across varied terrain. Currently located in Hunan, this joint-venture manufactured unit features a spacious cab design offering 360-degree visibility, reducing operator fatigue during extended shifts.
- Maximum digging depth of 3,133mm with 5,450mm reach radius
- Three bucket configurations (0.14/0.07/0.23 m³) for versatile applications
- Road-travel capability up to 18 km/h for efficient site-to-site mobility
- Compact transport dimensions (5,279mm length, 2,164mm width) for easy hauling
- 291mm ground clearance and 1,482mm rear turning radius for tight-space navigation
- Ergonomic controls and climate-controlled cabin reduce operator strain
- 70L hydraulic system with 25 MPa pressure for consistent lifting performance
Ideal for contractors requiring a reliable wheeled excavator with superior sightlines and intuitive handling for municipal, landscaping, and construct
| Specifications | Value |
|---|---|
| No. | 1017870 |
| Tonnage (tons) | 5 |
| Working weight (kg) | 5190 |
| Bucket capacity (m³) | 0.14/0.07/0.23 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Rated power (kw/rpm) | 33.7/2500 |
| Total displacement (L) | 2.2 |
| Forward speed (Km/h) | 18 |
| Rotation speed (rpm) | 10 |
| Main overflow set pressure (Mpa) | 25 |
| Fuel Tank (L) | 80 |
| Engine Oil changes (L) | 8 |
| Coolant (L) | 8 |
| Hydraulic System (L) | 70 |
| Total transport length (mm) | 5279 |
| Total transport width (mm) | 2164 |
| Total transport height (mm) | 2875 |
| Full cab height (mm) | 2875 |
| Counterweight ground clearance (mm) | 1025 |
| Wheelbase (mm) | 2050 |
| Total tire outside width (mm) | 2164 |
| Minimum ground clearance (mm) | 291 |
| Back end turning radius (mm) | 1482 |
| Maximum excavation radius (mm) | 5450 |
| Maximum digging depth (mm) | 3133 |
| Maximum excavation height (mm) | 5437 |
| Maximum unloading height (mm) | 3987 |
| Maximum vertical digging depth (mm) | 2026 |
