Product Description
Expand your operational capacity with this 2017 Volvo EW50 wheeled excavator, currently available in Shaoxing, Zhejiang. Built for contractors managing multiple jobsites simultaneously, this 5-ton machine delivers the mobility and performance needed to keep projects moving forward. Powered by a reliable 33.7kW engine with 2.2L displacement, it combines compact dimensions with serious digging capability—reaching 5,450mm excavation radius and 3,133mm maximum depth.
Key specifications for fleet managers:
- Working weight: 5,190kg with optimal maneuverability
- Triple bucket configuration: 0.14/0.07/0.23m³ capacity options
- Road speed: 18km/h for efficient site-to-site transit
- Compact transport dimensions: 5,279mm length × 2,164mm width
- Hydraulic system: 70L capacity with 25MPa main pressure
- Fuel efficiency: 80L tank for extended operation
Perfect as a backup unit during peak season or as a dedicated machine for utility work, drainage projects, and urban construction. Joint venture manufacturing ensures parts availability and service support. Add proven Volvo reliability to your equipment roster without the commitment of a primary excavator investment.
| Specifications | Value |
|---|---|
| No. | 1007290 |
| Tonnage (tons) | 5 |
| Working weight (kg) | 5190 |
| Bucket capacity (m³) | 0.14/0.07/0.23 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Rated power (kw/rpm) | 33.7/2500 |
| Total displacement (L) | 2.2 |
| Forward speed (Km/h) | 18 |
| Rotation speed (rpm) | 10 |
| Main overflow set pressure (Mpa) | 25 |
| Fuel Tank (L) | 80 |
| Engine Oil changes (L) | 8 |
| Coolant (L) | 8 |
| Hydraulic System (L) | 70 |
| Total transport length (mm) | 5279 |
| Total transport width (mm) | 2164 |
| Total transport height (mm) | 2875 |
| Full cab height (mm) | 2875 |
| Counterweight ground clearance (mm) | 1025 |
| Wheelbase (mm) | 2050 |
| Total tire outside width (mm) | 2164 |
| Minimum ground clearance (mm) | 291 |
| Back end turning radius (mm) | 1482 |
| Maximum excavation radius (mm) | 5450 |
| Maximum digging depth (mm) | 3133 |
| Maximum excavation height (mm) | 5437 |
| Maximum unloading height (mm) | 3987 |
| Maximum vertical digging depth (mm) | 2026 |
