Product Description
With a working weight of 5190 kg and a bucket capacity ranging from 0.07 to 0.23 m³, the 2018 Volvo EW50 is an ideal addition to any contractor's fleet. Featuring a rated power of 33.7 kW at 2500 rpm, this excavator ensures reliable performance for a variety of tasks. Its compact design, with a total transport length of 5279 mm and width of 2164 mm, makes it easy to maneuver on tight job sites.
- Equipped with a backhoe bucket, suitable for diverse excavation needs.
- Maximum digging depth of 3133 mm and maximum unloading height of 3987 mm, enhancing versatility.
- Efficient hydraulic system with a main overflow set pressure of 25 Mpa, ensuring smooth operation.
- Forward speed of 18 km/h and a rotation speed of 10 rpm, providing agility and control.
- Located in 广东惠州, ready for immediate integration into your existing fleet.
| Specifications | Value |
|---|---|
| No. | 1001007 |
| Tonnage (tons) | 5 |
| Working weight (kg) | 5190 |
| Bucket capacity (m³) | 0.14/0.07/0.23 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Rated power (kw/rpm) | 33.7/2500 |
| Total displacement (L) | 2.2 |
| Forward speed (Km/h) | 18 |
| Rotation speed (rpm) | 10 |
| Main overflow set pressure (Mpa) | 25 |
| Fuel Tank (L) | 80 |
| Engine Oil changes (L) | 8 |
| Coolant (L) | 8 |
| Hydraulic System (L) | 70 |
| Total transport length (mm) | 5279 |
| Total transport width (mm) | 2164 |
| Total transport height (mm) | 2875 |
| Full cab height (mm) | 2875 |
| Counterweight ground clearance (mm) | 1025 |
| Wheelbase (mm) | 2050 |
| Total tire outside width (mm) | 2164 |
| Minimum ground clearance (mm) | 291 |
| Back end turning radius (mm) | 1482 |
| Maximum excavation radius (mm) | 5450 |
| Maximum digging depth (mm) | 3133 |
| Maximum excavation height (mm) | 5437 |
| Maximum unloading height (mm) | 3987 |
| Maximum vertical digging depth (mm) | 2026 |
