Product Description
Engineered with precision, this 2018 Volvo EW50 wheeled excavator delivers exceptional performance through its robust 33.7kW power plant operating at 2500 rpm. The 2.2L total displacement engine combines with a sophisticated hydraulic system—featuring 25 MPa main overflow pressure and 70L capacity—to provide consistent, reliable power across demanding applications. Currently located in Maoming, Guangdong, this joint venture/import machine represents Volvo's commitment to superior construction equipment engineering.
- Working weight of 5,190 kg optimizes stability without sacrificing maneuverability
- Maximum excavation radius reaches 5,450 mm with 3,133 mm digging depth capability
- Versatile bucket configurations: 0.14/0.07/0.23 m³ capacity options for varied tasks
- 18 km/h forward speed and 10 rpm rotation speed enhance operational efficiency
- Compact transport dimensions (5,279 × 2,164 × 2,875 mm) facilitate site mobility
- 1,482 mm back-end turning radius enables work in confined spaces
Built on a proven 2,050 mm wheelbase with 291 mm ground clearance, this EW50 combines technical excellence with practical functionality for professional excavation operations.
| Specifications | Value |
|---|---|
| No. | 1008730 |
| Tonnage (tons) | 5 |
| Working weight (kg) | 5190 |
| Bucket capacity (m³) | 0.14/0.07/0.23 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Rated power (kw/rpm) | 33.7/2500 |
| Total displacement (L) | 2.2 |
| Forward speed (Km/h) | 18 |
| Rotation speed (rpm) | 10 |
| Main overflow set pressure (Mpa) | 25 |
| Fuel Tank (L) | 80 |
| Engine Oil changes (L) | 8 |
| Coolant (L) | 8 |
| Hydraulic System (L) | 70 |
| Total transport length (mm) | 5279 |
| Total transport width (mm) | 2164 |
| Total transport height (mm) | 2875 |
| Full cab height (mm) | 2875 |
| Counterweight ground clearance (mm) | 1025 |
| Wheelbase (mm) | 2050 |
| Total tire outside width (mm) | 2164 |
| Minimum ground clearance (mm) | 291 |
| Back end turning radius (mm) | 1482 |
| Maximum excavation radius (mm) | 5450 |
| Maximum digging depth (mm) | 3133 |
| Maximum excavation height (mm) | 5437 |
| Maximum unloading height (mm) | 3987 |
| Maximum vertical digging depth (mm) | 2026 |
