Product Description
Built to withstand demanding jobsite conditions, this 2020 Volvo EW50 wheeled excavator represents proven engineering excellence from a joint venture manufacturer. Operating at 5 tons with a working weight of 5,190 kg, this machine delivers consistent performance through its 33.7 kW rated power output and 2.2L total displacement engine. Four years of operational history demonstrate the robust construction and reliability that define Volvo's commitment to durability.
Equipped with versatile bucket configurations ranging from 0.07 to 0.23 m³ capacity, this workhorse handles diverse excavation tasks with precision. Maximum digging depth reaches 3,133 mm while excavation radius extends to 5,450 mm, providing substantial working range. The 70L hydraulic system operates at 25 Mpa main overflow pressure, ensuring powerful, controlled movements. Forward mobility of 18 km/h and compact transport dimensions (5,279 × 2,164 × 2,875 mm) facilitate efficient site-to-site transitions.
Currently located in Shaanxi Province, this proven excavator continues to demonstrate the longevity and dependable performance expected from Volvo construction equipment. Traditional power configuration ensures straightforward maintenance and sustaine
| Specifications | Value |
|---|---|
| No. | 1004762 |
| Tonnage (tons) | 5 |
| Working weight (kg) | 5190 |
| Bucket capacity (m³) | 0.14/0.07/0.23 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Rated power (kw/rpm) | 33.7/2500 |
| Total displacement (L) | 2.2 |
| Forward speed (Km/h) | 18 |
| Rotation speed (rpm) | 10 |
| Main overflow set pressure (Mpa) | 25 |
| Fuel Tank (L) | 80 |
| Engine Oil changes (L) | 8 |
| Coolant (L) | 8 |
| Hydraulic System (L) | 70 |
| Total transport length (mm) | 5279 |
| Total transport width (mm) | 2164 |
| Total transport height (mm) | 2875 |
| Full cab height (mm) | 2875 |
| Counterweight ground clearance (mm) | 1025 |
| Wheelbase (mm) | 2050 |
| Total tire outside width (mm) | 2164 |
| Minimum ground clearance (mm) | 291 |
| Back end turning radius (mm) | 1482 |
| Maximum excavation radius (mm) | 5450 |
| Maximum digging depth (mm) | 3133 |
| Maximum excavation height (mm) | 5437 |
| Maximum unloading height (mm) | 3987 |
| Maximum vertical digging depth (mm) | 2026 |
