Product Description
Built for immediate deployment on demanding job sites, this 2020 Volvo EW50 wheeled excavator delivers 33.7kW of reliable power across digging, grading, and material handling operations. Currently located in Maoming, Guangdong, this 5-ton machine combines compact dimensions with serious excavation capability—reaching 5450mm horizontally and digging 3133mm deep to tackle trenching, utility work, and foundation projects without hesitation.
Equipped with versatile bucket options (0.14/0.07/0.23 m³), the EW50 adapts quickly to changing site requirements. Its 18 km/h travel speed ensures efficient repositioning between work zones, while the 1482mm rear turning radius enables operation in confined urban environments. The 70L hydraulic system operates at 25 MPa, providing consistent breakout force and smooth control during precision work.
- Maximum unloading height: 3987mm for direct truck loading
- 2050mm wheelbase for stable operation on uneven terrain
- 80L fuel tank supports extended work shifts
- 291mm ground clearance navigates rough site conditions
Ready to work. No delays. This machine handles the tasks your project demands today.
| Specifications | Value |
|---|---|
| No. | 994879 |
| Tonnage (tons) | 5 |
| Working weight (kg) | 5190 |
| Bucket capacity (m³) | 0.14/0.07/0.23 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Rated power (kw/rpm) | 33.7/2500 |
| Total displacement (L) | 2.2 |
| Forward speed (Km/h) | 18 |
| Rotation speed (rpm) | 10 |
| Main overflow set pressure (Mpa) | 25 |
| Fuel Tank (L) | 80 |
| Engine Oil changes (L) | 8 |
| Coolant (L) | 8 |
| Hydraulic System (L) | 70 |
| Total transport length (mm) | 5279 |
| Total transport width (mm) | 2164 |
| Total transport height (mm) | 2875 |
| Full cab height (mm) | 2875 |
| Counterweight ground clearance (mm) | 1025 |
| Wheelbase (mm) | 2050 |
| Total tire outside width (mm) | 2164 |
| Minimum ground clearance (mm) | 291 |
| Back end turning radius (mm) | 1482 |
| Maximum excavation radius (mm) | 5450 |
| Maximum digging depth (mm) | 3133 |
| Maximum excavation height (mm) | 5437 |
| Maximum unloading height (mm) | 3987 |
| Maximum vertical digging depth (mm) | 2026 |
