Product Description
Proven in demanding jobsites since 2019, this Volvo EW70 wheeled excavator demonstrates the legendary durability that defines Swedish engineering. Operating at 7,250 kg working weight with a MITSUBISHI S4S engine delivering 41.2 kW of rated power, this machine combines mobility with serious digging capability. With a maximum excavation depth of 3,583 mm and reach extending to 6,354 mm, it tackles everything from utility work to urban construction with unwavering reliability. Currently located in Luzhou, Sichuan, this proven workhorse features a 20.5 km/h travel speed for efficient site-to-site mobility. Built to last through years of continuous operation, the EW70 offers triple bucket configurations (0.19/0.1/0.3 m³) and a robust hydraulic system holding 73 liters. Four years of service history validate its construction quality—a testament to Volvo's commitment to machines that earn their keep season after season. Ready for immediate deployment in your fleet.
- Working Weight: 7,250 kg with 7-ton capacity
- Engine: MITSUBISHI S4S, 41.2 kW @ 2,200 rpm
- Maximum Dig Depth: 3,583 mm | Reach: 6,354 mm
- Travel Speed: 20.5 km/h for superior mobility
- Bucket Options: 0.19/0.1/0.3 m³ configurations<
| Specifications | Value |
|---|---|
| No. | 1013261 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 7250 |
| Bucket capacity (m³) | 0.19/0.1/0.3 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | MITSUBISHI S4S |
| Rated power (kw/rpm) | 41.2/2200 |
| Total displacement (L) | 3.3 |
| Forward speed (Km/h) | 20.5 |
| Rotation speed (rpm) | 11 |
| Main overflow set pressure (Mpa) | 25 |
| Fuel Tank (L) | 110 |
| Engine Oil changes (L) | 10 |
| Coolant (L) | 15 |
| Hydraulic System (L) | 73 |
| Total transport length (mm) | 5893 |
| Total transport width (mm) | 2266 |
| Total transport height (mm) | 2963 |
| Full cab height (mm) | 2963 |
| Counterweight ground clearance (mm) | 1105 |
| Wheelbase (mm) | 2050 |
| Total tire outside width (mm) | 2266 |
| Minimum ground clearance (mm) | 361 |
| Back end turning radius (mm) | 1585 |
| Maximum excavation radius (mm) | 6354 |
| Maximum digging depth (mm) | 3583 |
| Maximum excavation height (mm) | 6702 |
| Maximum unloading height (mm) | 4950 |
| Maximum vertical digging depth (mm) | 1941 |
