Product Description
Built for demanding load-and-carry operations, this 2019 Volvo L250H wheel loader combines exceptional stability with operator-centered design. Powered by a robust D13J engine delivering 1100 N.m of torque, the machine handles bucket capacities from 2.7 to 9.5 m³ with confidence. Operating weight ranges between 34,000-35,300 kg, providing the mass needed for a 22,440 kg tipping load while maintaining balance through a 3750 mm wheelbase.
Operators benefit from outstanding sightlines across the 3170 mm width, critical when maneuvering in tight quarry or stockyard environments. The elevated cabin position at 1790 mm height enhances visibility over the loading zone. Volvo's HTL307 transmission delivers four progressive speeds up to 38 km/h, enabling efficient shuttle cycles. With a 13.1-second combined cycle time and 252 l/min hydraulic flow at rated speed, productivity remains consistently high.
- Location: Shaanxi Province, China
- Engine: D13J, 12.81L displacement
- Bucket Range: 2.7-9.5 m³
- Operating Weight: 34,000-35,300 kg
- Fuel Capacity: 366L for extended shifts
| Specifications | Value |
|---|---|
| No. | 1013544 |
| Engine type | D13J |
| Maximum torque (N.m/rpm) | 1100 |
| Exhaust volume (L) | 12.81 |
| Bucket capacity (m³) | 2,7 - 9,5 |
| Rated load (tons) | |
| Machine operating weight (kg) | 34000-35300 |
| Fuel Tank (L) | 366 |
| Hydraulic Tank (L) | 226 |
| Coolant (L) | 55 |
| Engine Oil (L) | 50 |
| Wheel base (mm) | 3750 |
| Minimum ground clearance (mm) | 540 |
| Machine length (mm) | 9490 |
| Machine width (mm) | 3170 |
| Machine height (mm) | 1790 |
| Flow rated speed (l/min) | 252 |
| Lift (s) | 7.1 |
| Unloading (s) | 1.9 |
| Lower empty bucket (s) | 4.1 |
| Ternary sum (s) | 13.1 |
| Gearbox brand and model | Volvo HTL307 |
| Speed 1 gear (km/h) | 7 |
| Speed 2 (km/h) | 11.5 |
| Speed 3 (km/h) | 24.5 |
| Speed 4 (km/h) | 38 |
| Tipping load (kg) | 22440 |
| Battery voltage (V) | |
| Starting motor Power (kw) | 7 |
