Product Description
Discover the 2016 Volvo L350F, a robust and reliable wheel loader available in Jiangxi, China. This machine is well-suited for demanding construction and mining operations, offering high performance and durability. With its powerful engine and efficient hydraulics, the L350F ensures optimal productivity and minimal downtime. Ideal for businesses looking to enhance their fleet with a dependable and versatile piece of equipment, this Volvo model is ready to meet your project's needs.
- Year: 2016
- Brand: Volvo
- Model: L350F
- Location: Jiangxi, China
| Specifications | Value |
|---|---|
| No. | 1082063 |
| Engine type | Volvo D16E LA E3 |
| Maximum torque (N.m) | 2550/1800 |
| Exhaust volume (L) | 16 |
| Rated power (kw/rpm) | 70 |
| Battery voltage (V) | 24 |
| Battery capacity (kWh) | 2x170 Ah |
| Bucket capacity (m³) | |
| Rated load (tons) | |
| Rated load (kg) | 37810-40030 |
| Digging force (lifting force) (kN) | 356.8-504.7 |
| Machine operating weight (kg) | 49810-51030 |
| Fuel Tank (L) | 620 |
| Hydraulic Tank (L) | 365 |
| Coolant (L) | 68 |
| Engine Oil (L) | 40 |
| Wheelbase (mm) | 4300 |
| Minimum ground clearance (mm) | 550 |
| Machine length (mm) | 8240 |
| Machine width (mm) | 3630 |
| Machine height (mm) | 4180 |
| Tyre specification | 35/65 R33 875/65 R33 |
| Hydraulic pump type | |
| Flow rated speed (l/min) | 354 |
| Rated working pressure (bars) | 260 |
| Lift (s) | 8 |
| Unloading (s) | 1.9 |
| Lower empty bucket (s) | 4.7 |
| Ternary sum (s) | 14.6 |
| Gearbox brand and model | Volvo HTE 400 |
| Speed 1 gear (km/h) | 6.8/7.5 |
| Speed 2 (km/h) | 12.1/13.2 |
| Speed 3 (km/h) | 21.0/22.9 |
| Speed 4 (km/h) | 35.7/38.2 |
| Tipping load (kg) | 34290 |
| Starting motor Power (kw) | 70 |
| Service brake | |
| Parking and emergency braking |
