Product Description
Discover the 2020 Volvo L350F, a robust and reliable wheel loader designed for demanding industrial applications. Located in Sichuan, China, this machine is equipped with original factory chains, ensuring durability and performance. The L350F is known for its exceptional productivity, efficiency, and operator comfort, making it an ideal choice for construction, mining, and material handling operations.
- Year: 2020
- Brand: Volvo
- Model: L350F
- Location: Sichuan, China
- Original Factory Chains
| Specifications | Value |
|---|---|
| No. | 1086402 |
| Engine type | Volvo D16E LA E3 |
| Maximum torque (N.m) | 2550/1800 |
| Exhaust volume (L) | 16 |
| Rated power (kw/rpm) | 70 |
| Battery voltage (V) | 24 |
| Battery capacity (kWh) | 2x170 Ah |
| Bucket capacity (m³) | |
| Rated load (tons) | |
| Rated load (kg) | 37810-40030 |
| Digging force (lifting force) (kN) | 356.8-504.7 |
| Machine operating weight (kg) | 49810-51030 |
| Fuel Tank (L) | 620 |
| Hydraulic Tank (L) | 365 |
| Coolant (L) | 68 |
| Engine Oil (L) | 40 |
| Wheelbase (mm) | 4300 |
| Minimum ground clearance (mm) | 550 |
| Machine length (mm) | 8240 |
| Machine width (mm) | 3630 |
| Machine height (mm) | 4180 |
| Tyre specification | 35/65 R33 875/65 R33 |
| Hydraulic pump type | |
| Flow rated speed (l/min) | 354 |
| Rated working pressure (bars) | 260 |
| Lift (s) | 8 |
| Unloading (s) | 1.9 |
| Lower empty bucket (s) | 4.7 |
| Ternary sum (s) | 14.6 |
| Gearbox brand and model | Volvo HTE 400 |
| Speed 1 gear (km/h) | 6.8/7.5 |
| Speed 2 (km/h) | 12.1/13.2 |
| Speed 3 (km/h) | 21.0/22.9 |
| Speed 4 (km/h) | 35.7/38.2 |
| Tipping load (kg) | 34290 |
| Starting motor Power (kw) | 70 |
| Service brake | |
| Parking and emergency braking |
