Product Description
Operators demand precision and comfort during extended shifts, and this 2017 XCMG 20K5 delivers both. Built with ergonomic controls and responsive hydraulics, this crane offers exceptional maneuverability for loading, lifting, and positioning tasks across construction and industrial sites. The cabin provides wide-angle visibility, reducing blind spots and enhancing safety during complex operations. Stability systems engineered into this model ensure confident performance even when working with maximum loads at extended reach.
- Year: 2017
- Brand: XCMG
- Model: 20K5
- Location: Anhui Huaibei, China
- Operator-focused cabin design with improved sightlines
- Responsive controls for precise load handling
- Proven stability for demanding lift applications
Currently located in Anhui Huaibei, this unit represents reliable Chinese engineering at a competitive price point. Ideal for contractors seeking dependable lifting capacity with operator comfort as a priority. Contact Fair Trade Machinery today for detailed specifications, inspection reports, and international shipping solutions.
| Specifications | Value |
|---|---|
| No. | 1013055 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 1.0-1.2 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2910 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | QSB7 |
| Rated power (kw/rpm) | 135/2050 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.7 |
| Working form | Direct injection, 4-stroke, turbocharged, air-to-air cold |
| Ground specific pressure (Kpa) | 47.5 |
| Rotation speed (rpm) | 12 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 157 |
| Rod digging force (kN) | 116 |
| Maximum tractive force (kN) | 184 |
| Travel speed (km/h) | 5.7/3.1 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 220 |
| Engine Oil changes (L) | 24 |
| Total transport length (mm) | 9630 |
| Total transport width (mm) | 2910 |
| Total transport height (mm) | 3100 |
| Counterweight ground clearance (mm) | 1050 |
| Minimum ground clearance (mm) | 486 |
| Minimum turning radius of front working device (mm) | 3530 |
| Back end turning radius (mm) | 2890 |
| Total track length (mm) | 4155 |
| Track gauge (mm) | 2290 |
| Total track width (mm) | 600 |
| Maximum digging radius (mm) | 9760 |
| Maximum digging depth (mm) | 6660 |
| Maximum excavation height (mm) | 9540 |
| Maximum unloading height (mm) | 6780 |
| Maximum vertical digging depth (mm) | 6480 |
