Product Description
Built for demanding job sites, this 2019 XCMG 20K5 excavator is configured and ready to put to work from day one. Currently located in Beijing, China, this machine delivers the digging force, grading precision, and demolition capability that contractors and operators depend on to meet tight project deadlines.
- Digging Performance: Powerful hydraulic system provides consistent breakout force for deep trenching and heavy earthmoving tasks
- Grading Accuracy: Responsive boom and arm control enables smooth, precise finish grading on roads, foundations, and slopes
- Demolition Ready: Robust undercarriage and structural integrity support attachment-based demolition work in tough operating conditions
- Model Year: 2019 — low accumulated wear relative to age, with years of productive service remaining
- Location: Beijing, China — well-positioned for cost-effective shipping across Asia and to international ports
Sourced directly from China's construction market, this XCMG 20K5 represents proven reliability at a competitive price point. Contact Fair Trade Machinery today for full inspection reports, specifications, and freight options.
| Specifications | Value |
|---|---|
| No. | 1056358 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21500 |
| Bucket capacity (m³) | 1.0-1.2 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2910 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | QSB7 |
| Rated power (kw/rpm) | 135/2050 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.7 |
| Working form | Direct injection, 4-stroke, turbocharged, air-to-air cold |
| Ground specific pressure (Kpa) | 47.5 |
| Rotation speed (rpm) | 12 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 157 |
| Rod digging force (kN) | 116 |
| Maximum tractive force (kN) | 184 |
| Travel speed (km/h) | 5.7/3.1 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 220 |
| Engine Oil changes (L) | 24 |
| Total transport length (mm) | 9630 |
| Total transport width (mm) | 2910 |
| Total transport height (mm) | 3100 |
| Counterweight ground clearance (mm) | 1050 |
| Minimum ground clearance (mm) | 486 |
| Minimum turning radius of front working device (mm) | 3530 |
| Back end turning radius (mm) | 2890 |
| Total track length (mm) | 4155 |
| Track gauge (mm) | 2290 |
| Total track width (mm) | 600 |
| Maximum digging radius (mm) | 9760 |
| Maximum digging depth (mm) | 6660 |
| Maximum excavation height (mm) | 9540 |
| Maximum unloading height (mm) | 6780 |
| Maximum vertical digging depth (mm) | 6480 |
