Product Description
Equipped with an advanced hydraulic system and precision joystick controls, this 2021 XCMG 70KD delivers responsive handling for operators managing demanding excavation tasks. Engineered for stability on uneven terrain, the reinforced undercarriage and optimized weight distribution ensure consistent performance across construction and infrastructure projects.
Operator comfort and productivity receive priority through thoughtful cabin design:
- Panoramic glass configuration provides 270-degree visibility, reducing blind spots during swing operations
- Ergonomic control layout minimizes fatigue during extended shifts
- Climate-controlled cabin maintains operational efficiency in varying weather conditions
- Low-vibration mounting system reduces operator strain
Currently located in Lianyungang, Jiangsu, this machine represents XCMG's 2021 production standards with documented service history. Hydraulic responsiveness and sight-line advantages make this excavator suitable for urban development, utility installation, and general earthmoving applications where operator precision directly impacts project timelines.
| Specifications | Value |
|---|---|
| No. | 1030689 |
| Tonnage (tons) | 27 |
| Working weight (kg) | 26500 |
| Bucket capacity (m³) | 1.1-1.4 |
| Boom length (mm) | 6000 |
| Rod length (mm) | 2964 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | QSB7 |
| Rated power (kw/rpm) | 150/2050 |
| Maximum torque (N.m) | 825/1250 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.7 |
| Working form | Efi, 4-stroke, turbocharged, air-to-air cold |
| Ground specific pressure (Kpa) | 52.1 |
| Rotation speed (rpm) | 11.4 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 185 |
| Rod digging force (kN) | 129 |
| Maximum tractive force (kN) | 220 |
| Travel speed (km/h) | 6.1/3.8 |
| Maximum flow of main pump (l/min) | 2*259 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 220 |
| Engine Oil changes (L) | 19.5 |
| Total transport length (mm) | 10170 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3175 |
| Counterweight ground clearance (mm) | 1090 |
| Minimum ground clearance (mm) | 495 |
| Minimum turning radius of front working device (mm) | 3510 |
| Back end turning radius (mm) | 2955 |
| Total track length (mm) | 4640 |
| Track gauge (mm) | 2590 |
| Total track width (mm) | 600 |
| Maximum digging radius (mm) | 10240 |
| Maximum digging depth (mm) | 6925 |
| Maximum excavation height (mm) | 10095 |
| Maximum unloading height (mm) | 7170 |
| Maximum vertical digging depth (mm) | 5620 |
