Product Description
Engineered with XCMG's advanced hydraulic system, this 2019 Model 70V delivers precise control and exceptional lifting performance across demanding industrial applications. Powered by a robust diesel engine meeting international emission standards, the unit combines fuel efficiency with reliable output for extended operational cycles. The hydraulic flow system ensures smooth boom and arm movements, while the reinforced structural design provides stability under maximum load conditions.
- Manufacturing Year: 2019
- Brand: XCMG
- Model: 70V
- Current Location: Wuxi, Jiangsu, China
Built on XCMG's proven engineering platform, the 70V series incorporates heavy-duty components designed for longevity in construction and material handling environments. The machine features an operator-focused cabin with optimized visibility and ergonomic controls. Currently positioned in Wuxi, this unit is available for immediate inspection and global export. All major systems have been maintained according to manufacturer specifications, ensuring reliable performance for your next project.
| Specifications | Value |
|---|---|
| No. | 1025652 |
| Tonnage (tons) | 27 |
| Working weight (kg) | 26500 |
| Bucket capacity (m³) | 1.1-1.4 |
| Boom length (mm) | 6000 |
| Rod length (mm) | 2964 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | QSB7 |
| Rated power (kw/rpm) | 150/2050 |
| Maximum torque (N.m) | 825/1250 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 6.7 |
| Working form | Efi, 4-stroke, turbocharged, air-to-air cold |
| Ground specific pressure (Kpa) | 52.1 |
| Rotation speed (rpm) | 11.4 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 185 |
| Rod digging force (kN) | 129 |
| Maximum tractive force (kN) | 220 |
| Travel speed (km/h) | 6.1/3.8 |
| Maximum flow of main pump (l/min) | 2*259 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 220 |
| Engine Oil changes (L) | 19.5 |
| Total transport length (mm) | 10170 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3175 |
| Counterweight ground clearance (mm) | 1090 |
| Minimum ground clearance (mm) | 495 |
| Minimum turning radius of front working device (mm) | 3510 |
| Back end turning radius (mm) | 2955 |
| Total track length (mm) | 4640 |
| Track gauge (mm) | 2590 |
| Total track width (mm) | 600 |
| Maximum digging radius (mm) | 10240 |
| Maximum digging depth (mm) | 6925 |
| Maximum excavation height (mm) | 10095 |
| Maximum unloading height (mm) | 7170 |
| Maximum vertical digging depth (mm) | 5620 |
