HOME>>XCMG>>XCMG 8B

2015 XCMG 8B

1/3
Buy XCMG 8B Used Crane / 1
Buy XCMG 8B Used Crane / 2
Buy XCMG 8B Used Crane / 3

Product Description

Well-maintained 2015 XCMG 8B excavator available in Shanxi, China. This China IV emission standard machine features an extended boom configuration with auxiliary arm attachment, enhancing versatility for diverse excavation tasks. The unit has been equipped with an aftermarket motor installation for improved fuel efficiency during operation.

  • Year: 2015
  • Make: XCMG
  • Model: 8B
  • Emission Standard: China IV
  • Boom: 3-section extended reach
  • Additional Equipment: Auxiliary arm, aftermarket motor
  • Documentation: Valid inspection and insurance through July 2027
  • Location: Shanxi, China

This machine offers reliable performance with documented compliance and fuel-efficient operation. The extended boom system provides enhanced reach capabilities for challenging job sites. Price negotiable for serious buyers.

SpecificationsValue
No.1140499
Tonnage (tons)2
Working weight (kg)1780
Bucket capacity (m³)0.044
Boom length (mm)1690
Rod length (mm)1100
Country of originXuzhou
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeYanmar Yanmar 3TNV82A
Rated power (kw/rpm)16.5/2200
Cooling modewater-cooling
Number of cylinders (PCS)3
Displacement (L)1.33
Ground specific pressure (Kpa)25.3
Rotation speed (rpm)11
Climbing ability (%)30 °
Bucket digging force (kN)13.9
Rod digging force (kN)8.8
Travel speed (km/h)4.4/2.4
Main overflow set pressure (Mpa)24
Rotary hydraulic motor typePlunger hydraulic motor
Type of walking hydraulic motorPlunger hydraulic motor
Maximum flow of main pump (l/min)2*19.8+14.1
Traveling Hydraulic Circuit (Mpa)21
Rotary Hydraulic Circuit (Mpa)18
Hydraulic crushing pipeline is standardis
Main pump typeJapan non Fukoshi variable pump ×2+ gear pump ×1
Pilot Oil Circuit (MPa)3.3
Fuel Tank (L)20
Hydraulic Tank (L)29
Engine Oil changes (L)5.5
Total transport length (mm)3760
Total transport width (mm)1300
Total transport height (mm)2405
Counterweight ground clearance (mm)509
Minimum ground clearance (mm)180
Minimum turning radius of front working device (mm)1675
Back end turning radius (mm)1190
Track gauge (mm)1070
Track plate width (mm)230
Track ground length (mm)1217
Maximum digging radius (mm)3915
Maximum digging depth (mm)2285
Maximum excavation height (mm)2655
Maximum unloading height (mm)2515
Maximum vertical digging depth (mm)1485
Dodging plate width × height (mm)1300 x 235
see more

Overview

No.1140499

Brand Name:

XCMG

Model Number:

8B

Year:

2015

Location:

Shanxi China

Pub Date
