Product Description
Engineered for mid-range loading applications, this 2018 XCMG LW200 wheel loader combines proven hydraulic architecture with efficient powertrain design. Powered by a 60kW engine operating at 2400 rpm, the machine delivers consistent torque across its 4-speed transmission range, reaching maximum travel speeds of 33 km/h for productive cycle times on mixed terrain.
Hydraulic performance centers on a 2000 kg rated load capacity with 60 kN digging force, supported by a 1.2 m³ bucket optimized for aggregates and bulk materials. Lift cycle completes in 6 seconds with full bucket-to-discharge sequence achieved in 11 seconds. Operating from a compact 2400 mm wheelbase, the loader maintains a 7500 kg working weight for stable operation while fitting a 5710 mm overall length.
Key Technical Specifications:
- Unloading height: 2650 mm at 45° discharge angle
- Reach: 910 mm forward clearance at standard dump position
- Dimensions: 2250 mm width × 2980 mm height
- Multi-speed transmission: 6.2–33 km/h operational range
- Current location: Zhejiang Province
| Specifications | Value |
|---|---|
| No. | 1018597 |
| Engine type | |
| Rated power (kw/rpm) | 60/2400 |
| Bucket capacity (m³) | 1.2 |
| Rated load (tons) | |
| Rated load (kg) | 2000 |
| Digging force (lifting force) (kN) | 60 |
| Machine operating weight (kg) | 7500 |
| Unloading height - Unloading Angle 45°(mm) | 2650 |
| Unloading distance - Unloading Angle 45°(mm) | 910 |
| Wheelbase (mm) | 2400 |
| Wheel base (mm) | 910 |
| Machine length (mm) | 5710 |
| Machine width (mm) | 2250 |
| Machine height (mm) | 2980 |
| Lift (s) | 6 |
| Ternary sum (s) | 11 |
| Speed 1 gear (km/h) | 6.2/8 |
| Speed 2 (km/h) | 12/28.5 |
| Speed 3 (km/h) | 20 |
| Speed 4 (km/h) | 33 |
