Product Description
Built for the demands of modern construction sites, this 2020 XCMG LW200 wheel loader delivers proven performance with a robust 60kW engine and 2000kg rated load capacity. Currently located in Sichuan, this workhorse combines durability with operational efficiency, featuring a 1.2m³ bucket capacity and 60kN digging force that tackles heavy-duty material handling with confidence. At 7,500kg operating weight, the machine maintains excellent stability while offering impressive reach specifications: 2,650mm unloading height and 910mm unloading distance at 45° angle.
- Engine Power: 60kW @ 2,400 RPM
- Load Capacity: 2,000kg rated load
- Bucket Capacity: 1.2m³
- Operating Weight: 7,500kg
- Dimensions: 5,710mm (L) × 2,250mm (W) × 2,980mm (H)
- Speed Range: Up to 33 km/h (4th gear)
- Cycle Times: 6s lift, 11s total cycle
Engineered to last, this compact loader represents XCMG's commitment to reliability and performance in challenging environments.
| Specifications | Value |
|---|---|
| No. | 1015139 |
| Engine type | |
| Rated power (kw/rpm) | 60/2400 |
| Bucket capacity (m³) | 1.2 |
| Rated load (tons) | |
| Rated load (kg) | 2000 |
| Digging force (lifting force) (kN) | 60 |
| Machine operating weight (kg) | 7500 |
| Unloading height - Unloading Angle 45°(mm) | 2650 |
| Unloading distance - Unloading Angle 45°(mm) | 910 |
| Wheelbase (mm) | 2400 |
| Wheel base (mm) | 910 |
| Machine length (mm) | 5710 |
| Machine width (mm) | 2250 |
| Machine height (mm) | 2980 |
| Lift (s) | 6 |
| Ternary sum (s) | 11 |
| Speed 1 gear (km/h) | 6.2/8 |
| Speed 2 (km/h) | 12/28.5 |
| Speed 3 (km/h) | 20 |
| Speed 4 (km/h) | 33 |
