Product Description
Built for immediate deployment, this 2022 XCMG LW200 wheel loader delivers proven performance across loading, grading, and material handling operations. Powered by a 60kW engine at 2400 rpm, this compact yet capable machine handles a 2000kg rated load with a 1.2m³ bucket capacity, making it ideal for construction sites, aggregate yards, and municipal projects.
Key specifications include:
- Operating weight: 7,500kg for excellent stability
- Breakout force: 60kN for tough material penetration
- Unloading height: 2,650mm at 45° angle
- Four-speed transmission: up to 33 km/h travel speed
- Compact dimensions: 5,710mm length × 2,250mm width
- Fast cycle times: 6-second lift, 11-second total cycle
Currently located in Heze, Shandong, this machine combines maneuverability with productivity. The 2,400mm wheelbase ensures stable operation while maintaining tight turning radius for confined work areas. Ready to integrate into your fleet and start generating returns from day one.
| Specifications | Value |
|---|---|
| No. | 1011659 |
| Engine type | |
| Rated power (kw/rpm) | 60/2400 |
| Bucket capacity (m³) | 1.2 |
| Rated load (tons) | |
| Rated load (kg) | 2000 |
| Digging force (lifting force) (kN) | 60 |
| Machine operating weight (kg) | 7500 |
| Unloading height - Unloading Angle 45°(mm) | 2650 |
| Unloading distance - Unloading Angle 45°(mm) | 910 |
| Wheelbase (mm) | 2400 |
| Wheel base (mm) | 910 |
| Machine length (mm) | 5710 |
| Machine width (mm) | 2250 |
| Machine height (mm) | 2980 |
| Lift (s) | 6 |
| Ternary sum (s) | 11 |
| Speed 1 gear (km/h) | 6.2/8 |
| Speed 2 (km/h) | 12/28.5 |
| Speed 3 (km/h) | 20 |
| Speed 4 (km/h) | 33 |
