Product Description
Engineered for mid-range construction and material handling, this 2022 XCMG LW200 wheel loader delivers 60kW at 2400 rpm through a proven powertrain designed for continuous-duty cycles. With a rated load capacity of 2000kg and 1.2m³ bucket capacity, the machine achieves optimal balance between payload efficiency and operational agility. Hydraulic performance includes 60kN of breakout force, enabling effective penetration in compacted materials and stockpile work.
Compact dimensions—5710mm length, 2250mm width, 2980mm height—provide maneuverability in confined job sites while maintaining stability through a 2400mm wheelbase. Operating weight of 7500kg ensures ground engagement without sacrificing transportability. Four-speed transmission offers ranges from 6.2 km/h in first gear to 33 km/h in fourth, supporting varied applications from precision loading to rapid repositioning.
Located in Wenzhou, Zhejiang, this unit represents XCMG's reputation for durable construction-grade equipment. Unloading height reaches 2650mm at 45° angle with 910mm reach, compatible with standard truck bed heights. Six-second lift cycle and eleven-second total cycle time maximize productivity in aggregate, demolition, and general contracting
| Specifications | Value |
|---|---|
| No. | 1017760 |
| Engine type | |
| Rated power (kw/rpm) | 60/2400 |
| Bucket capacity (m³) | 1.2 |
| Rated load (tons) | |
| Rated load (kg) | 2000 |
| Digging force (lifting force) (kN) | 60 |
| Machine operating weight (kg) | 7500 |
| Unloading height - Unloading Angle 45°(mm) | 2650 |
| Unloading distance - Unloading Angle 45°(mm) | 910 |
| Wheelbase (mm) | 2400 |
| Wheel base (mm) | 910 |
| Machine length (mm) | 5710 |
| Machine width (mm) | 2250 |
| Machine height (mm) | 2980 |
| Lift (s) | 6 |
| Ternary sum (s) | 11 |
| Speed 1 gear (km/h) | 6.2/8 |
| Speed 2 (km/h) | 12/28.5 |
| Speed 3 (km/h) | 20 |
| Speed 4 (km/h) | 33 |
