Product Description
Engineered for heavy-duty performance, this 2016 XCMG LW500KL wheel loader delivers 162 kW of rated power at 2000 rpm, backed by a robust torque output of 900 N·m. Hydraulic systems are optimized for efficiency with a 200-liter tank capacity, while the 3.0 m³ bucket handles 5,000 kg rated loads with a digging force of 170 kN. Operating weight stands at 17,200 kg, providing stability across demanding jobsites.
- Maximum unloading height: 3,090 mm with 1,130 mm reach
- Tractive force: 175 kN for superior traction and material handling
- Climbing capability: 35° gradient performance
- Cycle efficiency: 6-second lift, 11-second combined cycle time
- Fuel capacity: 295 liters for extended operation
- Turning radius: 6,910 mm (outside of bucket)
- 23.5-25-16PR tire specification on 3,300 mm wheelbase
Currently located in Baoding, Hebei, this loader combines proven XCMG engineering with practical specifications suited for construction, mining, and material handling operations requiring reliable productivity and consistent uptime.
| Specifications | Value |
|---|---|
| No. | 1017274 |
| Engine type | |
| Rated power (kw/rpm) | 162/2000 |
| Cooling mode | |
| Maximum torque (N.m) | 900 |
| Working form | |
| Bucket capacity (m³) | 3 |
| Rated load (tons) | |
| Rated load (kg) | 5000 |
| Digging force (lifting force) (kN) | 170 |
| Machine operating weight (kg) | 17200 |
| Max - Unloading height (mm) | 3090 |
| Unloading distance (mm) | 1130 |
| Maximum tractive force (kN) | 175 |
| Maximum climbing ability (°) | 35 |
| Fuel Tank (L) | 295 |
| Hydraulic Tank (L) | 200 |
| Coolant (L) | 45 |
| Wheelbase (mm) | 3300 |
| Wheel base (mm) | 2250 |
| Machine length (mm) | 8185 |
| Machine width (mm) | 3000 |
| Machine height (mm) | 3465 |
| Tyre specification | 23.5-25-16PR |
| Steering Angle | |
| Turning radius - Outside of bucket (mm) | 6910 |
| Lift (s) | 6 |
| Ternary sum (s) | 11 |
| Speed 1 gear (km/h) | |
| Speed 2 (km/h) | 36 |
