Product Description
Backed by one of China's most established heavy equipment manufacturers, this 2021 XCMG LW520F wheel loader delivers proven performance with 162kW of rated power and a 5,000kg rated load capacity. Currently located in Chongqing, this machine combines robust engineering with the long-term support network that XCMG operators depend on worldwide.
Key specifications include:
- Bucket capacity: 2.7m³ with 145kN digging force
- Operating weight: 16,200kg for optimal stability
- Maximum tractive force: 140kN
- Unloading height: 3,130mm at 45° angle
- Two-speed transmission: 11.5km/h and 37km/h
- Compact turning radius: 5,670mm
XCMG's global parts distribution network and strong resale values make this loader a financially sound investment. With widespread dealer support across Asia, Africa, and beyond, maintenance downtime remains minimal. Operating dimensions of 7,702mm length × 3,000mm width ensure maneuverability on confined job sites while maintaining the durability XCMG built its reputation on since 1989.
| Specifications | Value |
|---|---|
| No. | 1029980 |
| Engine type | |
| Rated power (kw/rpm) | 162/2200 |
| Cylinder diameter × stroke (mm) | |
| Bucket capacity (m³) | 2.7 |
| Rated load (tons) | |
| Rated load (kg) | 5000 |
| Digging force (lifting force) (kN) | 145 |
| Machine operating weight (kg) | 16200 |
| Unloading height - Unloading Angle 45°(mm) | 3130 |
| Unloading distance - Unloading Angle 45°(mm) | 1220 |
| Maximum tractive force (kN) | 140 |
| Tipping load (kg) | 10000 |
| Minimum ground clearance (mm) | 450 |
| Machine length (mm) | 7702 |
| Machine width (mm) | 3000 |
| Machine height (mm) | 3280 |
| Steering Angle | |
| Minimum turning radius of outer wheel center line | 5670 |
| Ternary sum (s) | 12 |
| Speed 1 gear (km/h) | 11.5 |
| Speed 2 (km/h) | 37 |
