Product Description
With a Cummins QSM11(Tier2) engine delivering 250 kW of power, this 2021 XCMG LW800K loader is a robust choice for demanding tasks. Located in 浙江温州, it offers a maximum torque of 1647 N.m at 1400 rpm, ensuring reliable performance. The machine boasts a bucket capacity of 4.5 m³ and a rated load of 8000 kg, making it ideal for heavy-duty operations. Its digging force of 260 kN and maximum tractive force of 245 kN enhance its efficiency on the job site. Weighing 28500 kg, this loader features an unloading height of 3400 mm and an unloading distance of 1400 mm at a 45° angle, facilitating versatile use. Equipped with a 420 L fuel tank, it ensures long operational hours. This used XCMG LW800K is a smart investment, offering high performance at a fraction of the cost of a new model.
| Specifications | Value |
|---|---|
| No. | 1018721 |
| Engine type | Cummins QSM11(Tier2) |
| Rated power (kw/rpm) | 250/2100 |
| Cooling mode | |
| Maximum torque (N.m/rpm) | 1647/1400 |
| Working form | |
| Exhaust volume (L) | 10.8 |
| Bucket capacity (m³) | 4.5 |
| Rated load (tons) | |
| Rated load (kg) | 8000 |
| Digging force (lifting force) (kN) | 260 |
| Machine operating weight (kg) | 28500 |
| Unloading height - Unloading Angle 45°(mm) | 3400 |
| Unloading distance - Unloading Angle 45°(mm) | 1400 |
| Maximum tractive force (kN) | 245 |
| Fuel Tank (L) | 420 |
| Coolant (L) | 65 |
| Engine Oil (L) | 33 |
| Wheelbase (mm) | 3600 |
| Wheel base (mm) | 2460 |
| Minimum ground clearance (mm) | 520 |
| Machine length (mm) | 9300 |
| Machine width (mm) | 3500 |
| Machine height (mm) | 3770 |
| Maximum total height (mm) | 6230 |
| Bucket width (mm) | 3500 |
| Transaxle swing Angle (°) | |
| Tyre specification | 29.5-25-22PR |
| Steering Angle | |
| Minimum turning radius of outer wheel center line | 6200 |
| Hydraulic pump type | |
| Flow rated speed (l/min) | 168 |
| Rated working pressure (bars) | 190 |
| Boom cylinder diameter × stroke (mm×mm) | |
| Bucket cylinder diameter × stroke (mm×mm) | |
| Lift (s) | <6 |
| Unloading (s) | <1.2 |
| Lower empty bucket (s) | <3.6 |
| Ternary sum (s) | 10.8 |
| Gearbox brand and model | |
| Speed 1 gear (km/h) | |
| Speed 2 (km/h) | |
| Speed 3 (km/h) | |
| Speed 4 (km/h) | |
| Gear setting | |
| Maximum speed (km/h) | 35.5 |
