Product Description
Engineered for high-capacity loading operations, this 2022 XCMG LW800K delivers industrial-grade performance through proven mechanical systems. Powered by a Cummins QSM11 Tier 2 engine producing 250 kW at 2100 rpm and 1647 N·m maximum torque, this wheel loader handles demanding material handling tasks with an 8,000 kg rated load capacity and 4.5 m³ bucket.
Hydraulic efficiency defines operational capability: a 168 l/min flow rate at 190 bar working pressure drives a complete load cycle in 10.8 seconds, with bucket lift completed in under 6 seconds. Breakout force reaches 260 kN, ensuring effective penetration in compacted materials. The 28,500 kg operating weight provides stability during full-bucket transport, while the 245 kN maximum tractive force maintains productivity across varied terrain.
Key specifications include:
- 3,600 mm wheelbase with 520 mm ground clearance for job site mobility
- 3,400 mm unloading height at 45° dump angle
- 6,200 mm minimum turning radius for confined-area maneuverability
- 35.5 km/h maximum travel speed on 29.5-25-22PR tires
- 420 L fuel capacity for extended operational shifts
Currently located in Guizhou, China, available for g
| Specifications | Value |
|---|---|
| No. | 1022302 |
| Engine type | Cummins QSM11(Tier2) |
| Rated power (kw/rpm) | 250/2100 |
| Cooling mode | |
| Maximum torque (N.m/rpm) | 1647/1400 |
| Working form | |
| Exhaust volume (L) | 10.8 |
| Bucket capacity (m³) | 4.5 |
| Rated load (tons) | |
| Rated load (kg) | 8000 |
| Digging force (lifting force) (kN) | 260 |
| Machine operating weight (kg) | 28500 |
| Unloading height - Unloading Angle 45°(mm) | 3400 |
| Unloading distance - Unloading Angle 45°(mm) | 1400 |
| Maximum tractive force (kN) | 245 |
| Fuel Tank (L) | 420 |
| Coolant (L) | 65 |
| Engine Oil (L) | 33 |
| Wheelbase (mm) | 3600 |
| Wheel base (mm) | 2460 |
| Minimum ground clearance (mm) | 520 |
| Machine length (mm) | 9300 |
| Machine width (mm) | 3500 |
| Machine height (mm) | 3770 |
| Maximum total height (mm) | 6230 |
| Bucket width (mm) | 3500 |
| Transaxle swing Angle (°) | |
| Tyre specification | 29.5-25-22PR |
| Steering Angle | |
| Minimum turning radius of outer wheel center line | 6200 |
| Hydraulic pump type | |
| Flow rated speed (l/min) | 168 |
| Rated working pressure (bars) | 190 |
| Boom cylinder diameter × stroke (mm×mm) | |
| Bucket cylinder diameter × stroke (mm×mm) | |
| Lift (s) | <6 |
| Unloading (s) | <1.2 |
| Lower empty bucket (s) | <3.6 |
| Ternary sum (s) | 10.8 |
| Gearbox brand and model | |
| Speed 1 gear (km/h) | |
| Speed 2 (km/h) | |
| Speed 3 (km/h) | |
| Speed 4 (km/h) | |
| Gear setting | |
| Maximum speed (km/h) | 35.5 |
