2019 XCMG Xct8

1/3
Buy XCMG Xct8 Used Crane / 1
Buy XCMG Xct8 Used Crane / 2
Buy XCMG Xct8 Used Crane / 3

Product Description

Discover the 2019 XCMG Xct8, a robust and reliable used crane, available for immediate purchase. Located in Hebei, China, this machine has been meticulously maintained by a single owner since its acquisition in January 2019. Notably, it has never been operated by external drivers, ensuring a consistent and well-documented maintenance history. Recent updates include a new battery, fresh steel cables, and a fully functional air conditioning system, enhancing both performance and operator comfort. This Xct8 is ready to meet your project demands with its enduring build quality and operational efficiency.

  • Year: 2019
  • Brand: XCMG
  • Model: Xct8
  • Location: Hebei, China
  • Key Features: New battery, new steel ropes, working AC
SpecificationsValue
No.1112809
Tonnage (tons)2
Working weight (kg)1780
Bucket capacity (m³)0.044
Boom length (mm)1690
Rod length (mm)1100
Country of originXuzhou
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeYanmar Yanmar 3TNV82A
Rated power (kw/rpm)16.5/2200
Cooling modewater-cooling
Number of cylinders (PCS)3
Displacement (L)1.33
Ground specific pressure (Kpa)25.3
Rotation speed (rpm)11
Climbing ability (%)30 °
Bucket digging force (kN)13.9
Rod digging force (kN)8.8
Travel speed (km/h)4.4/2.4
Main overflow set pressure (Mpa)24
Rotary hydraulic motor typePlunger hydraulic motor
Type of walking hydraulic motorPlunger hydraulic motor
Maximum flow of main pump (l/min)2*19.8+14.1
Traveling Hydraulic Circuit (Mpa)21
Rotary Hydraulic Circuit (Mpa)18
Hydraulic crushing pipeline is standardis
Main pump typeJapan non Fukoshi variable pump ×2+ gear pump ×1
Pilot Oil Circuit (MPa)3.3
Fuel Tank (L)20
Hydraulic Tank (L)29
Engine Oil changes (L)5.5
Total transport length (mm)3760
Total transport width (mm)1300
Total transport height (mm)2405
Counterweight ground clearance (mm)509
Minimum ground clearance (mm)180
Minimum turning radius of front working device (mm)1675
Back end turning radius (mm)1190
Track gauge (mm)1070
Track plate width (mm)230
Track ground length (mm)1217
Maximum digging radius (mm)3915
Maximum digging depth (mm)2285
Maximum excavation height (mm)2655
Maximum unloading height (mm)2515
Maximum vertical digging depth (mm)1485
Dodging plate width × height (mm)1300 x 235
see more

Overview

No.1112809

Brand Name:

XCMG

Model Number:

Xct8

Year:

2019

Location:

Hebei China

Pub Date
