Product Description
Available now from our Fujian facility, this 2015 XCMG XE135B delivers 13-ton performance without the factory wait. Powered by an ISUZU BB-4BG1TRP engine generating 69.6kW at 2200rpm, this excavator features a 0.4-0.52m³ bucket capacity and twin plunger pumps delivering 2×123 L/min flow for responsive hydraulic power. Maximum digging reach extends to 8,296mm with 5,538mm depth capability, while 85kN bucket digging force handles demanding excavation tasks.
Skip the lead times—fast deployment to your site means production starts immediately. Built in Xuzhou with proven water-cooled 4-cylinder turbo technology, this machine offers:
- 13,800kg working weight with 42kPa ground pressure for site versatility
- 4,600mm boom and 2,510mm arm configuration for optimal reach
- 35° climbing ability and 12.3rpm rotation speed
- Dual-speed travel: 5.16/3.03 km/h for efficient repositioning
- 250L fuel and 130L hydraulic tank capacity for extended operation
Located in Fujian for immediate shipment. Contact us today to secure this ready-to-work excavator and bypass months of factory production delays.
| Specifications | Value |
|---|---|
| No. | 1023761 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 13800 |
| Bucket capacity (m³) | 0.4-0.52 |
| Boom length (mm) | 4600 |
| Rod length (mm) | 2510 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | ISUZU BB-4BG1TRP |
| Rated power (kw/rpm) | 69.6/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.329 |
| Working form | turbocharging |
| Ground specific pressure (Kpa) | 42 |
| Rotation speed (rpm) | 12.3 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 85 |
| Rod digging force (kN) | 65 |
| Travel speed (km/h) | 5.16/3.03 |
| Main overflow set pressure (Mpa) | 31.4/34.3 |
| Maximum flow of main pump (l/min) | 2*123 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 25 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Two plunger pumps |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 130 |
| Engine Oil changes (L) | 14 |
| Total transport length (mm) | 7770 |
| Total transport width (mm) | 2512 |
| Total transport height (mm) | 2880 |
| Counterweight ground clearance (mm) | 964 |
| Minimum ground clearance (mm) | 478 |
| Minimum turning radius of front working device (mm) | 2335 |
| Back end turning radius (mm) | 2294 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Track ground length (mm) | 2910 |
| Maximum digging radius (mm) | 8296 |
| Maximum digging depth (mm) | 5538 |
| Maximum excavation height (mm) | 8641 |
| Maximum unloading height (mm) | 6181 |
| Maximum vertical digging depth (mm) | 4727 |
