Product Description
Engineered with precision in Xuzhou, this 13-ton excavator delivers exceptional hydraulic performance through its dual plunger pump system, generating 2×123 L/min maximum flow at 31.4/34.3 MPa main overflow pressure. Power comes from the proven ISUZU BB-4BG1TRP turbocharged engine, producing 69.6 kW at 2200 rpm through its 4.329L displacement and water-cooling system for sustained reliability in demanding applications.
Operational capacity stands out with an 8,296mm maximum digging radius and 5,538mm digging depth, while the 0.4-0.52 m³ bucket delivers 85 kN digging force. The 4,600mm boom and 2,510mm arm configuration provides 6,181mm maximum unloading height, optimizing loading cycles. Hydraulic circuits operate at precisely calibrated pressures—34.3 MPa for travel, 25 MPa for rotation—ensuring responsive control across all functions.
Key Technical Specifications:
- Working weight: 13,800 kg with 42 kPa ground pressure
- Travel speeds: 5.16/3.03 km/h with 35° climbing capability
- Fuel capacity: 250L tank supporting extended operation
- Transport dimensions: 7,770mm × 2,512mm × 2,880mm
- Currently located in Fuzhou, Jiangxi for immediate inspection
| Specifications | Value |
|---|---|
| No. | 1030033 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 13800 |
| Bucket capacity (m³) | 0.4-0.52 |
| Boom length (mm) | 4600 |
| Rod length (mm) | 2510 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | ISUZU BB-4BG1TRP |
| Rated power (kw/rpm) | 69.6/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.329 |
| Working form | turbocharging |
| Ground specific pressure (Kpa) | 42 |
| Rotation speed (rpm) | 12.3 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 85 |
| Rod digging force (kN) | 65 |
| Travel speed (km/h) | 5.16/3.03 |
| Main overflow set pressure (Mpa) | 31.4/34.3 |
| Maximum flow of main pump (l/min) | 2*123 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 25 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Two plunger pumps |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 130 |
| Engine Oil changes (L) | 14 |
| Total transport length (mm) | 7770 |
| Total transport width (mm) | 2512 |
| Total transport height (mm) | 2880 |
| Counterweight ground clearance (mm) | 964 |
| Minimum ground clearance (mm) | 478 |
| Minimum turning radius of front working device (mm) | 2335 |
| Back end turning radius (mm) | 2294 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Track ground length (mm) | 2910 |
| Maximum digging radius (mm) | 8296 |
| Maximum digging depth (mm) | 5538 |
| Maximum excavation height (mm) | 8641 |
| Maximum unloading height (mm) | 6181 |
| Maximum vertical digging depth (mm) | 4727 |
