Product Description
Strengthen your operational capacity with this 2016 XCMG XE135B excavator, a proven 13-ton workhorse engineered for contractors demanding reliable fleet performance. Powered by an ISUZU BB-4BG1TRP turbocharged engine delivering 69.6 kW at 2200 rpm, this Chinese-manufactured unit combines water-cooled efficiency with robust hydraulic power. Dual plunger pumps supply 2×123 l/min flow, while the 0.4-0.52 m³ backhoe bucket generates 85 kN digging force—ideal for medium-duty excavation, trenching, and site preparation.
- Maximum Digging Reach: 8,296 mm with 5,538 mm depth capability
- Hydraulic Performance: 31.4/34.3 MPa main overflow pressure for consistent cycle times
- Mobility: 2,335 mm minimum turning radius; 35° climbing ability
- Fuel Autonomy: 250 L tank capacity for extended shifts
- Compact Transport: 7,770 mm length fits standard lowboys
Currently located in Guangzhou, Guangdong, this XE135B integrates seamlessly alongside larger excavators, maintaining productivity during peak workloads or equipment rotations. Contact Fair Trade Machinery for shipping quotes and operational docu
| Specifications | Value |
|---|---|
| No. | 1031837 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 13800 |
| Bucket capacity (m³) | 0.4-0.52 |
| Boom length (mm) | 4600 |
| Rod length (mm) | 2510 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | ISUZU BB-4BG1TRP |
| Rated power (kw/rpm) | 69.6/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.329 |
| Working form | turbocharging |
| Ground specific pressure (Kpa) | 42 |
| Rotation speed (rpm) | 12.3 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 85 |
| Rod digging force (kN) | 65 |
| Travel speed (km/h) | 5.16/3.03 |
| Main overflow set pressure (Mpa) | 31.4/34.3 |
| Maximum flow of main pump (l/min) | 2*123 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 25 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Two plunger pumps |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 130 |
| Engine Oil changes (L) | 14 |
| Total transport length (mm) | 7770 |
| Total transport width (mm) | 2512 |
| Total transport height (mm) | 2880 |
| Counterweight ground clearance (mm) | 964 |
| Minimum ground clearance (mm) | 478 |
| Minimum turning radius of front working device (mm) | 2335 |
| Back end turning radius (mm) | 2294 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Track ground length (mm) | 2910 |
| Maximum digging radius (mm) | 8296 |
| Maximum digging depth (mm) | 5538 |
| Maximum excavation height (mm) | 8641 |
| Maximum unloading height (mm) | 6181 |
| Maximum vertical digging depth (mm) | 4727 |
