Product Description
Proven in demanding conditions since 2018, this XCMG XE135B excavator delivers reliable performance backed by solid engineering. Operating at 13 tons with a 13,800 kg working weight, this machine combines the power of an ISUZU BB-4BG1TRP engine (69.6 kW) with a robust hydraulic system featuring dual plunger pumps and 2×123 l/min flow capacity. Built to last through heavy-duty applications, it offers an impressive 8,296 mm maximum digging radius and 5,538 mm digging depth, while the 0.4-0.52 m³ bucket capacity ensures productive cycle times.
- Bucket digging force: 85 kN for tough material penetration
- Water-cooled turbocharged engine with 4.329L displacement
- 35° climbing ability handles challenging terrain
- Compact transport dimensions: 7,770 × 2,512 × 2,880 mm
- Xuzhou manufacturing heritage ensures quality components
- Currently located in Sichuan, ready for deployment
With four years of proven field operation, this workhorse demonstrates XCMG's commitment to durability. Comprehensive hydraulic circuits operating at optimized pressures guarantee consistent performance shift after shift, making this XE135B a dependable choice for contractors seeking value
| Specifications | Value |
|---|---|
| No. | 1029545 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 13800 |
| Bucket capacity (m³) | 0.4-0.52 |
| Boom length (mm) | 4600 |
| Rod length (mm) | 2510 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | ISUZU BB-4BG1TRP |
| Rated power (kw/rpm) | 69.6/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.329 |
| Working form | turbocharging |
| Ground specific pressure (Kpa) | 42 |
| Rotation speed (rpm) | 12.3 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 85 |
| Rod digging force (kN) | 65 |
| Travel speed (km/h) | 5.16/3.03 |
| Main overflow set pressure (Mpa) | 31.4/34.3 |
| Maximum flow of main pump (l/min) | 2*123 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 25 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Two plunger pumps |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 130 |
| Engine Oil changes (L) | 14 |
| Total transport length (mm) | 7770 |
| Total transport width (mm) | 2512 |
| Total transport height (mm) | 2880 |
| Counterweight ground clearance (mm) | 964 |
| Minimum ground clearance (mm) | 478 |
| Minimum turning radius of front working device (mm) | 2335 |
| Back end turning radius (mm) | 2294 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Track ground length (mm) | 2910 |
| Maximum digging radius (mm) | 8296 |
| Maximum digging depth (mm) | 5538 |
| Maximum excavation height (mm) | 8641 |
| Maximum unloading height (mm) | 6181 |
| Maximum vertical digging depth (mm) | 4727 |
