Built to endure the toughest jobsites, this 2019 XCMG XE135B excavator delivers proven performance across medium-duty applications. With 13 tons of operational weight and a robust ISUZU BB-4BG1TRP engine producing 69.6kW, this workhorse combines power with precision. Its 0.4-0.52 m³ bucket capacity and impressive 8,296mm maximum digging radius make it ideal for construction, utility work, and site development.
- Proven Reliability: ISUZU turbocharged engine with water-cooling system ensures consistent performance in demanding conditions
- Exceptional Reach: 5,538mm maximum digging depth and 8,641mm excavation height expand your operational capabilities
- Operator Efficiency: Dual plunger pumps (2×123 L/min) provide responsive hydraulic control for precise movements
- Terrain Versatility: 35° climbing ability and 42 Kpa ground pressure enable work on challenging ground conditions
- Work-Ready Configuration: Standard backhoe bucket with 85kN digging force tackles tough excavation tasks
Currently located in Lishui, Zhejiang, this proven performer represents dependable Chinese engineering ready for
| Specifications | Value |
|---|---|
| No. | 1019743 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 13800 |
| Bucket capacity (m³) | 0.4-0.52 |
| Boom length (mm) | 4600 |
| Rod length (mm) | 2510 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | ISUZU BB-4BG1TRP |
| Rated power (kw/rpm) | 69.6/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.329 |
| Working form | turbocharging |
| Ground specific pressure (Kpa) | 42 |
| Rotation speed (rpm) | 12.3 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 85 |
| Rod digging force (kN) | 65 |
| Travel speed (km/h) | 5.16/3.03 |
| Main overflow set pressure (Mpa) | 31.4/34.3 |
| Maximum flow of main pump (l/min) | 2*123 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 25 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Two plunger pumps |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 130 |
| Engine Oil changes (L) | 14 |
| Total transport length (mm) | 7770 |
| Total transport width (mm) | 2512 |
| Total transport height (mm) | 2880 |
| Counterweight ground clearance (mm) | 964 |
| Minimum ground clearance (mm) | 478 |
| Minimum turning radius of front working device (mm) | 2335 |
| Back end turning radius (mm) | 2294 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Track ground length (mm) | 2910 |
| Maximum digging radius (mm) | 8296 |
| Maximum digging depth (mm) | 5538 |
| Maximum excavation height (mm) | 8641 |
| Maximum unloading height (mm) | 6181 |
| Maximum vertical digging depth (mm) | 4727 |
