Product Description
Engineered with precision in Xuzhou, this 13-ton excavator combines proven hydraulic architecture with robust mechanical performance. Powered by an ISUZU BB-4BG1TRP turbocharged engine delivering 69.6kW at 2200rpm, the XE135B provides reliable output across demanding applications. Dual plunger pumps supply 2×123 L/min flow at 31.4/34.3 MPa main overflow pressure, ensuring responsive cycle times and consistent digging force—85kN bucket force and 65kN arm force handle compacted materials with authority.
Operating specifications demonstrate well-balanced design:
- Maximum digging reach: 8,296mm with 5,538mm depth capability
- Working weight: 13,800kg with 0.4–0.52m³ bucket capacity
- 4,600mm boom and 2,510mm arm configuration for versatile geometry
- Water-cooled 4-cylinder engine (4.329L displacement) for thermal stability
- 35° gradeability with 12.3rpm slew speed
Standard hydraulic systems include dedicated circuits for travel (34.3 MPa) and rotation (25 MPa), with 250L fuel and 130L hydraulic reservoirs supporting extended shifts. Currently located in Wenzhou, Zhejiang. Suitable for contractors requiring proven mid-size excavation capacity with established component reli
| Specifications | Value |
|---|---|
| No. | 1028425 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 13800 |
| Bucket capacity (m³) | 0.4-0.52 |
| Boom length (mm) | 4600 |
| Rod length (mm) | 2510 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | ISUZU BB-4BG1TRP |
| Rated power (kw/rpm) | 69.6/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.329 |
| Working form | turbocharging |
| Ground specific pressure (Kpa) | 42 |
| Rotation speed (rpm) | 12.3 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 85 |
| Rod digging force (kN) | 65 |
| Travel speed (km/h) | 5.16/3.03 |
| Main overflow set pressure (Mpa) | 31.4/34.3 |
| Maximum flow of main pump (l/min) | 2*123 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 25 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Two plunger pumps |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 130 |
| Engine Oil changes (L) | 14 |
| Total transport length (mm) | 7770 |
| Total transport width (mm) | 2512 |
| Total transport height (mm) | 2880 |
| Counterweight ground clearance (mm) | 964 |
| Minimum ground clearance (mm) | 478 |
| Minimum turning radius of front working device (mm) | 2335 |
| Back end turning radius (mm) | 2294 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Track ground length (mm) | 2910 |
| Maximum digging radius (mm) | 8296 |
| Maximum digging depth (mm) | 5538 |
| Maximum excavation height (mm) | 8641 |
| Maximum unloading height (mm) | 6181 |
| Maximum vertical digging depth (mm) | 4727 |
