Product Description
Maximize your excavation budget with this 2021 XCMG XE135B, delivering flagship performance at a fraction of new equipment costs. Powered by a robust ISUZU 4-cylinder turbocharged engine producing 69.6kW, this 13-ton workhorse combines proven reliability with impressive productivity across demanding job sites. Currently located in Zhejiang Lishui, this machine offers immediate deployment potential for contractors seeking professional-grade capabilities without premium pricing.
Engineered for versatility, the XE135B features an 8,296mm maximum digging radius and 5,538mm maximum depth, handling everything from foundation work to utility installations. The dual plunger hydraulic system delivers 2×123 L/min flow with 85kN bucket digging force, ensuring efficient material handling in tough conditions. With a 0.4-0.52m³ bucket capacity and 35° climbing ability, this excavator tackles challenging terrain while maintaining exceptional stability through its 2,910mm track ground length.
Key Investment Advantages:
- Low operational hours on 2021 model—minimal depreciation remaining
- Factory ISUZU power plant ensures parts availability and service support
- Standard water-cooling system
| Specifications | Value |
|---|---|
| No. | 1019747 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 13800 |
| Bucket capacity (m³) | 0.4-0.52 |
| Boom length (mm) | 4600 |
| Rod length (mm) | 2510 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | ISUZU BB-4BG1TRP |
| Rated power (kw/rpm) | 69.6/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.329 |
| Working form | turbocharging |
| Ground specific pressure (Kpa) | 42 |
| Rotation speed (rpm) | 12.3 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 85 |
| Rod digging force (kN) | 65 |
| Travel speed (km/h) | 5.16/3.03 |
| Main overflow set pressure (Mpa) | 31.4/34.3 |
| Maximum flow of main pump (l/min) | 2*123 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 25 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Two plunger pumps |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 130 |
| Engine Oil changes (L) | 14 |
| Total transport length (mm) | 7770 |
| Total transport width (mm) | 2512 |
| Total transport height (mm) | 2880 |
| Counterweight ground clearance (mm) | 964 |
| Minimum ground clearance (mm) | 478 |
| Minimum turning radius of front working device (mm) | 2335 |
| Back end turning radius (mm) | 2294 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Track ground length (mm) | 2910 |
| Maximum digging radius (mm) | 8296 |
| Maximum digging depth (mm) | 5538 |
| Maximum excavation height (mm) | 8641 |
| Maximum unloading height (mm) | 6181 |
| Maximum vertical digging depth (mm) | 4727 |
