Product Description
Acquire proven performance without the premium price tag. This 2023 XCMG XE135B excavator from Liuzhou, Guangxi delivers 13-ton capacity with barely any operational hours—offering you near-new reliability at a fraction of dealer cost. Powered by a robust ISUZU BB-4BG1TRP engine producing 69.6kW, this machine handles demanding jobsites with 85kN bucket digging force and an impressive 8,296mm maximum reach.
Built in Xuzhou with proven engineering, the XE135B features dual plunger pumps delivering 2×123 L/min flow, water-cooled turbocharged performance, and 0.4-0.52m³ bucket capacity for versatile excavation work. With 35° climbing ability and 5,538mm maximum dig depth, this excavator tackles challenging terrain while maintaining 42kPa ground pressure for minimal site disturbance.
- 13,800kg working weight with 4,600mm boom reach
- ISUZU 4-cylinder turbocharged diesel: 4.329L displacement
- 250L fuel tank and 130L hydraulic reservoir for extended operation
- Compact transport dimensions: 7,770mm × 2,512mm × 2,880mm
- 12.3 RPM rotation speed for efficient cycle times
Smart buyers recognize value: near-new condition, manufacturer warranty eligibility, and immediate availabili
| Specifications | Value |
|---|---|
| No. | 1039356 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 13800 |
| Bucket capacity (m³) | 0.4-0.52 |
| Boom length (mm) | 4600 |
| Rod length (mm) | 2510 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | ISUZU BB-4BG1TRP |
| Rated power (kw/rpm) | 69.6/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.329 |
| Working form | turbocharging |
| Ground specific pressure (Kpa) | 42 |
| Rotation speed (rpm) | 12.3 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 85 |
| Rod digging force (kN) | 65 |
| Travel speed (km/h) | 5.16/3.03 |
| Main overflow set pressure (Mpa) | 31.4/34.3 |
| Maximum flow of main pump (l/min) | 2*123 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 25 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Two plunger pumps |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 130 |
| Engine Oil changes (L) | 14 |
| Total transport length (mm) | 7770 |
| Total transport width (mm) | 2512 |
| Total transport height (mm) | 2880 |
| Counterweight ground clearance (mm) | 964 |
| Minimum ground clearance (mm) | 478 |
| Minimum turning radius of front working device (mm) | 2335 |
| Back end turning radius (mm) | 2294 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Track ground length (mm) | 2910 |
| Maximum digging radius (mm) | 8296 |
| Maximum digging depth (mm) | 5538 |
| Maximum excavation height (mm) | 8641 |
| Maximum unloading height (mm) | 6181 |
| Maximum vertical digging depth (mm) | 4727 |
