2023 XCMG XE135B

1/5
Buy XCMG XE135B Used Excavator / 1
Buy XCMG XE135B Used Excavator / 2
Buy XCMG XE135B Used Excavator / 3
Buy XCMG XE135B Used Excavator / 4
Buy XCMG XE135B Used Excavator / 5

Product Description

This 2023 XCMG XE135B excavator offers proven reliability with 2,600 operational hours. Currently located in Zhejiang, China, this 13.5-ton class machine represents excellent value for contractors seeking dependable performance in a nearly new package.

The XE135B is engineered for demanding earthmoving applications, featuring XCMG's robust hydraulic system and fuel-efficient power delivery. With minimal hours for a 2023 unit, this excavator has substantial service life remaining.

  • Year: 2023
  • Operating Hours: 2,600
  • Location: Zhejiang Province, China
  • Condition: Used, operational

Ideal for excavation, trenching, and material handling across construction and infrastructure projects. Ready for inspection and immediate deployment. Contact us for detailed specifications, current condition reports, and competitive export pricing.

SpecificationsValue
No.1110317
Tonnage (tons)13
Working weight (kg)13800
Bucket capacity (m³)0.4-0.52
Boom length (mm)4600
Rod length (mm)2510
Country of originXuzhou
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeISUZU BB-4BG1TRP
Rated power (kw/rpm)69.6/2200
Cooling modewater-cooling
Number of cylinders (PCS)4
Displacement (L)4.329
Working formturbocharging
Ground specific pressure (Kpa)42
Rotation speed (rpm)12.3
Climbing ability (%)35 °
Bucket digging force (kN)85
Rod digging force (kN)65
Travel speed (km/h)5.16/3.03
Main overflow set pressure (Mpa)31.4/34.3
Maximum flow of main pump (l/min)2*123
Traveling Hydraulic Circuit (Mpa)34.3
Rotary Hydraulic Circuit (Mpa)25
Hydraulic crushing pipeline is standardno
Main pump typeTwo plunger pumps
Pilot Oil Circuit (MPa)3.9
Fuel Tank (L)250
Hydraulic Tank (L)130
Engine Oil changes (L)14
Total transport length (mm)7770
Total transport width (mm)2512
Total transport height (mm)2880
Counterweight ground clearance (mm)964
Minimum ground clearance (mm)478
Minimum turning radius of front working device (mm)2335
Back end turning radius (mm)2294
Track gauge (mm)1990
Track plate width (mm)500
Track ground length (mm)2910
Maximum digging radius (mm)8296
Maximum digging depth (mm)5538
Maximum excavation height (mm)8641
Maximum unloading height (mm)6181
Maximum vertical digging depth (mm)4727
see more

Overview

No.1110317

Brand Name:

XCMG

Model Number:

XE135B

Year:

2023

Location:

Zhejiang China

Pub Date
