2023 XCMG XE135B

1/6
Buy XCMG XE135B Used Excavator / 1
Buy XCMG XE135B Used Excavator / 2
Buy XCMG XE135B Used Excavator / 3
Buy XCMG XE135B Used Excavator / 4
Buy XCMG XE135B Used Excavator / 5
Buy XCMG XE135B Used Excavator / 6

Product Description

This 2023 XCMG XE135B excavator represents excellent value in the mid-size crawler excavator segment. Currently located in Zhejiang, China, this machine offers competitive pricing for buyers seeking reliable earthmoving equipment from a leading Chinese manufacturer.

The XE135B is XCMG's proven 13.5-ton class excavator, designed for versatility across construction, infrastructure, and material handling applications. With approximately one year of service, this unit combines modern features with minimal operational hours.

  • Operating weight: Approximately 13,500 kg
  • Bucket capacity: 0.5 m³ standard
  • Engine: Tier 3 compliant diesel
  • Hydraulic system optimized for fuel efficiency
  • Suitable for general excavation, trenching, and loading operations

Ideal for contractors and fleet operators looking to expand capacity with a cost-effective, late-model machine. Inspection welcomed prior to purchase.

SpecificationsValue
No.1119528
Tonnage (tons)13
Working weight (kg)13800
Bucket capacity (m³)0.4-0.52
Boom length (mm)4600
Rod length (mm)2510
Country of originXuzhou
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeISUZU BB-4BG1TRP
Rated power (kw/rpm)69.6/2200
Cooling modewater-cooling
Number of cylinders (PCS)4
Displacement (L)4.329
Working formturbocharging
Ground specific pressure (Kpa)42
Rotation speed (rpm)12.3
Climbing ability (%)35 °
Bucket digging force (kN)85
Rod digging force (kN)65
Travel speed (km/h)5.16/3.03
Main overflow set pressure (Mpa)31.4/34.3
Maximum flow of main pump (l/min)2*123
Traveling Hydraulic Circuit (Mpa)34.3
Rotary Hydraulic Circuit (Mpa)25
Hydraulic crushing pipeline is standardno
Main pump typeTwo plunger pumps
Pilot Oil Circuit (MPa)3.9
Fuel Tank (L)250
Hydraulic Tank (L)130
Engine Oil changes (L)14
Total transport length (mm)7770
Total transport width (mm)2512
Total transport height (mm)2880
Counterweight ground clearance (mm)964
Minimum ground clearance (mm)478
Minimum turning radius of front working device (mm)2335
Back end turning radius (mm)2294
Track gauge (mm)1990
Track plate width (mm)500
Track ground length (mm)2910
Maximum digging radius (mm)8296
Maximum digging depth (mm)5538
Maximum excavation height (mm)8641
Maximum unloading height (mm)6181
Maximum vertical digging depth (mm)4727
see more

Overview

No.1119528

Brand Name:

XCMG

Model Number:

XE135B

Year:

2023

Location:

Zhejiang China

Pub Date
