Product Description
Built for precision and power, this 2024 XCMG XE135B excavator delivers reliable performance across demanding job sites. Operating at 13 tons with a robust ISUZU BB-4BG1TRP engine producing 69.6kW, this machine tackles excavation, grading, and material handling with proven efficiency. The 0.4-0.52 m³ bucket capacity and 85kN bucket digging force cut through tough ground conditions, while the 8296mm maximum digging radius and 5538mm digging depth provide exceptional reach for foundation work and trenching operations.
Currently located in Zhejiang Lishui, this Xuzhou-manufactured excavator arrives ready for immediate deployment. Key operational specifications include:
- 13,800kg working weight with 42 kPa ground pressure for stable operation
- Dual plunger hydraulic pumps (2×123 L/min) ensuring responsive control
- 35° climbing ability for challenging terrain access
- Water-cooled turbocharged 4-cylinder engine with 4.329L displacement
- Compact transport dimensions: 7770mm × 2512mm × 2880mm
- 250L fuel capacity for extended runtime between refills
Site-tested engineering meets practical design in a machine built to work from day one.
| Specifications | Value |
|---|---|
| No. | 1020026 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 13800 |
| Bucket capacity (m³) | 0.4-0.52 |
| Boom length (mm) | 4600 |
| Rod length (mm) | 2510 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | ISUZU BB-4BG1TRP |
| Rated power (kw/rpm) | 69.6/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.329 |
| Working form | turbocharging |
| Ground specific pressure (Kpa) | 42 |
| Rotation speed (rpm) | 12.3 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 85 |
| Rod digging force (kN) | 65 |
| Travel speed (km/h) | 5.16/3.03 |
| Main overflow set pressure (Mpa) | 31.4/34.3 |
| Maximum flow of main pump (l/min) | 2*123 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 25 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Two plunger pumps |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 130 |
| Engine Oil changes (L) | 14 |
| Total transport length (mm) | 7770 |
| Total transport width (mm) | 2512 |
| Total transport height (mm) | 2880 |
| Counterweight ground clearance (mm) | 964 |
| Minimum ground clearance (mm) | 478 |
| Minimum turning radius of front working device (mm) | 2335 |
| Back end turning radius (mm) | 2294 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Track ground length (mm) | 2910 |
| Maximum digging radius (mm) | 8296 |
| Maximum digging depth (mm) | 5538 |
| Maximum excavation height (mm) | 8641 |
| Maximum unloading height (mm) | 6181 |
| Maximum vertical digging depth (mm) | 4727 |
