Product Description
Built for demanding excavation work, this 2018 XCMG XE135D represents a strategic investment in proven Chinese engineering. Operating at 13 tons with a robust QSF3.8 engine delivering 86kW of rated power, this mid-size excavator combines reliable performance with exceptional value retention. XCMG's extensive dealer network ensures parts availability remains consistent throughout China, minimizing downtime and protecting your operational budget.
Currently located in Guangzhou, Guangdong, this machine features a 0.52m³ bucket capacity and impressive digging specifications: 8304mm maximum reach and 5546mm maximum depth. The water-cooled, turbocharged engine provides 470N.m of torque, while dual main pumps deliver 125.4L/min each for responsive hydraulic performance.
Key advantages of choosing XCMG in the used market include:
- Strong resale value backed by brand recognition across Asia-Pacific markets
- Widespread parts distribution network reducing procurement costs
- Proven track record with over 13,200kg working weight for stability
- Comprehensive service support from authorized centers nationwide
With 99.1kN bucket digging force and 35% climbing ability, this XE135D de
| Specifications | Value |
|---|---|
| No. | 996214 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 13200 |
| Bucket capacity (m³) | 0.32-0.61 (0.52) |
| Boom length (mm) | 4600 |
| Rod length (mm) | 2520 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | QSF3.8 |
| Rated power (kw/rpm) | 86/2200 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 470/1300 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.8 |
| Working form | Efi, Direct injection, 4-stroke, turbocharged |
| Ground specific pressure (Kpa) | 40.4 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 99.1 |
| Rod digging force (kN) | 68 |
| Maximum tractive force (kN) | 134 |
| Travel speed (km/h) | 5.2/2.9 |
| Maximum flow of main pump (l/min) | 125.4*2 |
| Traveling Hydraulic Circuit (Mpa) | 34.4 |
| Rotary Hydraulic Circuit (Mpa) | 25 |
| Working Hydraulic Circuit (Mpa) | 31.4/34.3 |
| Fuel Tank (L) | 260 |
| Hydraulic Tank (L) | 105 |
| Engine Oil changes (L) | 11 |
| Total transport length (mm) | 7795 |
| Total transport width (mm) | 2525 |
| Total transport height (mm) | 2880 |
| Counterweight ground clearance (mm) | 931 |
| Minimum ground clearance (mm) | 466 |
| Minimum turning radius of front working device (mm) | 2445 |
| Back end turning radius (mm) | 2325 |
| Total track length (mm) | 3648 |
| Track gauge (mm) | 1990 |
| Total track width (mm) | 500 |
| Maximum digging radius (mm) | 8304 |
| Maximum digging depth (mm) | 5546 |
| Maximum excavation height (mm) | 8638 |
| Maximum unloading height (mm) | 6174 |
| Maximum vertical digging depth (mm) | 4698 |
| Maximum effective digging depth (mm) | 5335 |
