Product Description
Built for precision and daily productivity, this 2020 XCMG XE135D delivers 13-ton performance with operator-centered engineering. Powered by a QSF3.8 engine producing 86kW at 2200 rpm, the machine combines 470 N.m torque with responsive hydraulic flow of 125.4 L/min per pump for smooth, controlled movements across demanding job sites.
Operators benefit from excellent sightlines and stable platform design. With a ground-specific pressure of just 40.4 kPa and 500mm track width, the XE135D maintains balance on soft terrain while delivering 99.1 kN bucket digging force. The spacious cabin provides clear visibility to the 8304mm maximum digging radius, while 11 rpm rotation speed ensures confident positioning without jarring movement.
- Working weight: 13,200 kg with 0.52 m³ standard bucket
- Maximum digging depth: 5,546 mm; reach: 8,304 mm
- Water-cooled turbocharged engine with direct injection efficiency
- Dual-speed travel: 5.2/2.9 km/h for transport and precision work
- 260L fuel capacity for extended shifts
- Currently located in Hangzhou, Zhejiang
| Specifications | Value |
|---|---|
| No. | 1028459 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 13200 |
| Bucket capacity (m³) | 0.32-0.61 (0.52) |
| Boom length (mm) | 4600 |
| Rod length (mm) | 2520 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | QSF3.8 |
| Rated power (kw/rpm) | 86/2200 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 470/1300 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.8 |
| Working form | Efi, Direct injection, 4-stroke, turbocharged |
| Ground specific pressure (Kpa) | 40.4 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 99.1 |
| Rod digging force (kN) | 68 |
| Maximum tractive force (kN) | 134 |
| Travel speed (km/h) | 5.2/2.9 |
| Maximum flow of main pump (l/min) | 125.4*2 |
| Traveling Hydraulic Circuit (Mpa) | 34.4 |
| Rotary Hydraulic Circuit (Mpa) | 25 |
| Working Hydraulic Circuit (Mpa) | 31.4/34.3 |
| Fuel Tank (L) | 260 |
| Hydraulic Tank (L) | 105 |
| Engine Oil changes (L) | 11 |
| Total transport length (mm) | 7795 |
| Total transport width (mm) | 2525 |
| Total transport height (mm) | 2880 |
| Counterweight ground clearance (mm) | 931 |
| Minimum ground clearance (mm) | 466 |
| Minimum turning radius of front working device (mm) | 2445 |
| Back end turning radius (mm) | 2325 |
| Total track length (mm) | 3648 |
| Track gauge (mm) | 1990 |
| Total track width (mm) | 500 |
| Maximum digging radius (mm) | 8304 |
| Maximum digging depth (mm) | 5546 |
| Maximum excavation height (mm) | 8638 |
| Maximum unloading height (mm) | 6174 |
| Maximum vertical digging depth (mm) | 4698 |
| Maximum effective digging depth (mm) | 5335 |
