Name: Used Excavators 2021 XCMG XE135D
Brand: XCMG
SKU: USED-1038360
Availability: InStock
Rating: 4.6 (03 reviews)

Sany

Caterpillar

XCMG

Hitachi

Komatsu

Doosan

Kobelco

Hyundai

Volvo

Sumitomo

Kato

Case

Yanmar

JohnDeere

Liebherr

Expand your fleet capacity with this 2021 XCMG XE135D crawler excavator, currently positioned in Nanning, Guangxi. Operating at 13 tons with a 13,200 kg working weight, this mid-size machine delivers reliable backup support for contractors managing multiple jobsites or seasonal demand spikes. Powered by a QSF3.8 turbocharged engine producing 86 kW at 2,200 rpm, it provides consistent performance across standard excavation, trenching, and material handling applications.

<ul>
<li>Digging Performance: 8,304 mm max reach, 5,546 mm depth, 99.1 kN bucket force</li>
<li>Hydraulic System: Dual main pumps (125.4 L/min each) with 31.4/34.3 MPa working pressure</li>
<li>Versatile Bucket Range: 0.32–0.61 m³ capacity for varied applications</li>
<li>Operational Specs: 4,600 mm boom, 2,520 mm arm, 35% gradeability</li>
<li>Fuel Efficiency: 260 L tank capacity for extended shifts</li>
<li>Transport Dimensions: 7,795 × 2,525 × 2,880 mm</li>
</ul>

Built in China by XCMG with water-cooled direct injection technology, this unit integrates seamlessly into existing equipment rosters requiring proven 13-ton class performance without premium inve

Strengthen your fleet capacity with this reliable 2021 Komatsu PC200-8 excavator, currently located in Jiangsu. Built for contractors managing multiple job sites, this 20-ton workhorse delivers consistent performance when your primary equipment is deployed elsewhere. Powered by a Komatsu SAA6D107E-1 engine producing 110kW at 2000rpm, this machine meets EPA Tier 3 and EUIIIA emission standards while maintaining robust digging forces of 149kN (bucket) and 108kN (arm).

<ul>
<li>Operating weight: 19,900kg with 0.8m³ bucket capacity</li>
<li>Maximum digging reach: 9,875mm; depth: 6,620mm</li>
<li>Proven hydraulic system: 439 L/min main pump flow for responsive operation</li>
<li>Efficient fuel management: 400L tank capacity for extended shifts</li>
<li>Compact transport dimensions: 9,480mm × 2,800mm × 3,040mm</li>
<li>Superior climbing ability: 70% grade capability</li>
</ul>

Manufactured in Jining, Shandong Province, this joint venture model provides the backup reliability your operation demands. With standard specifications including 5,700mm boom and 2,925mm arm, this PC200-8 integrates seamlessly into existing Komatsu fleets while offering versatile performance across excavation, loading, and grading applications.

Komatsu PC200-8

Built for high-production excavation, this 2014 Caterpillar 336E delivers 236 kW of reliable power through its CAT C9ACERT engine. With a 35,500 kg working weight and 36-ton capacity, this machine tackles demanding digging, grading, and demolition work across construction and mining sites. The 11,040 mm maximum digging radius provides exceptional reach for loading trucks, trenching utilities, or clearing foundations without repositioning.

Key specifications include:
<ul>
<li>Caterpillar C9ACERT engine: 236 kW at 1,800 rpm with water-cooling</li>
<li>First-generation Stage IIIB/Tier 4 emissions compliance</li>
<li>Backhoe configuration for versatile excavation tasks</li>
<li>Joint venture/Import manufacturer quality standards</li>
<li>Currently located in Shanghai for inspection</li>
</ul>

Designed for operators requiring immediate deployment, this 336E combines proven hydraulics with fuel-efficient performance. Site-ready condition means reduced downtime between acquisition and production. Contact Fair Trade Machinery today to arrange equipment evaluation or discuss shipping logistics to your project location.

Caterpillar 336E

Engineered for precision and all-day productivity, this 2019 Sany SY205C delivers exceptional operator comfort and control across demanding jobsites. Powered by a robust 118kW engine at 2000rpm, this 20-ton excavator combines responsive hydraulics with superior visibility from its full-height cabin, enabling accurate positioning and confident operation in tight spaces.

<ul>
 <li>Optimized Operator Environment: Spacious cab design with panoramic visibility and ergonomic controls reduces fatigue during extended shifts</li>
 <li>Precise Maneuverability: 2900mm rear turning radius and 3730mm front working device radius facilitate work in confined areas</li>
 <li>Stable Performance: 21,500kg working weight and 47.3kPa ground pressure deliver reliable stability without excessive ground disturbance</li>
 <li>Versatile Reach: 10,280mm maximum digging radius and 6,600mm digging depth handle diverse excavation requirements</li>
 <li>Smooth Operation: 11rpm rotation speed and dual travel speeds (5.4/3.3 km/h) provide controlled, efficient movement</li>
</ul>

Currently located in Nanchang, Jiangxi, this Chinese-manufactured excavator offers depend

Sany SY205C

Built for heavy-duty excavation and earthmoving, this 2016 Komatsu PC270-7 delivers 27 tons of working weight with immediate deployment capability. Powered by a Komatsu SAA6D102E-2 engine producing 134 kW at 2050 rpm, this machine tackles demanding job sites with a 1.3 m³ bucket capacity and 198 kN bucket digging force. Reach extends to 10,100 mm maximum digging radius while penetrating depths up to 6,460 mm—ideal for foundation work, trenching, and large-scale excavation projects.

Equipped with dual axial piston travel motors and a 450 L/min main pump, this excavator provides responsive hydraulic performance for grading, loading, and demolition tasks. Water-cooled 6-cylinder turbocharged engine meets EPA Tier 3 and EU Stage IIIA emissions standards. Currently located in Shanghai and site-ready for immediate operation.

<ul>
<li>Operating weight: 27,460 kg with proven stability</li>
<li>Maximum digging depth: 6,460 mm for deep excavation</li>
<li>Bucket digging force: 198 kN for tough soil conditions</li>
<li>Travel speed: Up to 5.5 km/h for efficient repositioning</li>
<li>400 L fuel capacity for extended operation</li>
</ul>

Komatsu PC270-7

Strengthen your fleet capacity with this 2021 XCMG XE380K crawler excavator, currently positioned in Wenzhou, Zhejiang. Operating at 38 tons with a 38,500 kg working weight, this diesel-powered machine delivers 254 kW at 1900 rpm—ideal for contractors managing multiple job sites simultaneously. Equipped with a backhoe bucket offering 1.9-2.1 m³ capacity and 292 kN digging force, it handles bulk earthmoving, trenching, and loading operations with consistent reliability.

<ul>
<li>Year: 2021</li>
<li>Model: XCMG XE380K</li>
<li>Operating Weight: 38,500 kg</li>
<li>Rated Power: 254 kW @ 1900 rpm</li>
<li>Bucket Capacity: 1.9-2.1 m³</li>
<li>Digging Force: 292 kN</li>
<li>Maximum Reach: 10,968 mm</li>
<li>Fuel Type: Diesel</li>
<li>Origin: Made in China</li>
<li>Location: Wenzhou, Zhejiang</li>
</ul>

Deploy this excavator as a backup unit during peak demand periods or integrate it permanently to expand operational capacity. Contact Fair Trade Machinery for specifications, shipping logistics, and competitive fleet pricing.

XCMG XE380K

Engineered with Caterpillar's proven Cat C4.2 ACERT engine delivering 67 kW of net power, this 2023 313D excavator combines robust hydraulics with precision control for demanding jobsites. The water-cooled 4.25L displacement engine meets US EPA Tier 3 and European IIIA emissions standards while maintaining exceptional fuel efficiency from its 250L tank capacity.

Hydraulic performance defines this 13-ton machine's capabilities:
<ul>
<li>Maximum main pump flow of 127 L/min ensures responsive operation</li>
<li>82 kN bucket digging force and 63 kN rod digging force tackle tough materials</li>
<li>30.5 MPa main overflow pressure provides consistent power delivery</li>
<li>8,220 mm maximum excavation radius covers extensive work areas</li>
<li>5,580 mm maximum digging depth handles deep foundation work</li>
</ul>

Built at Xuzhou, Jiangsu under joint venture manufacturing standards, this 313D features a 4,650 mm boom and 2,500 mm rod configuration optimized for versatility. With 13,430 kg operating weight, 500 mm standard track plates, and 41.8 kPa ground pressure, this excavator balances stability with minimal surface disruption. Currently located in Wenzhou, Zhejiang, ready for immediate deployment.

Caterpillar 313D

Engineered for precision work in demanding environments, this 2018 Hyundai R210W excavator delivers reliable performance for mid-scale construction and earthmoving operations. Operating at 21 tons with traditional power systems, this joint venture model combines proven hydraulic technology with operator-centered design principles that defined Hyundai's second-generation wheeled excavators.

Operator advantages include:
<ul>
<li>Enhanced cabin visibility with panoramic glazing for improved site awareness and safety during backhoe operations</li>
<li>Intuitive hydraulic controls providing responsive handling across varied terrain conditions</li>
<li>Stabilized platform design minimizing lateral movement during boom extension and slewing</li>
<li>Ergonomic workstation layout reducing operator fatigue during extended shifts</li>
<li>Reinforced undercarriage delivering consistent stability on Shanghai's mixed urban and industrial sites</li>
</ul>

Currently located in Shanghai, this wheeled excavator offers the mobility and versatility required for projects demanding frequent relocation without sacrificing the digging power of tracked counterparts. Suitable for contractors prioritizing operator comfort and machine uptime in

Hyundai R210W

Engineered with Caterpillar's proven CAT C13 ACERT engine delivering 283 kW of rated power across 6 cylinders and 12.5L displacement, this 2011 345D excavator represents precision heavy-duty performance. Operating at 45 tons with a working weight of 45,375 kg, this machine combines exceptional hydraulic flow—734 L/min from the main pump—with robust digging capabilities including 8,920 mm maximum depth and 12,940 mm excavation radius at stop surface.

<ul>
<li>Bucket capacity: 1.8-3.5 m³ backhoe configuration</li>
<li>Superior hydraulic system: 570L total capacity for sustained performance</li>
<li>Rotation speed: 8.7 rpm for efficient cycle times</li>
<li>Maximum unloading height: 7,820 mm</li>
<li>Climbing ability: 70% (35°) for challenging terrain</li>
<li>Fuel capacity: 705L for extended operation</li>
<li>Transport dimensions: 12,450 mm length × 3,680 mm height</li>
</ul>

Currently located in Shanghai, this joint venture/imported unit from Japan maintains Caterpillar's engineering standards with dual travel speeds (2.8/4.5 km/h) and comprehensive vertical digging depth of 5,860 mm. Built for demanding applications requiring reliable power and precision control.

Caterpillar 345D

Expand your operational capacity with this 2016 Kobelco SK250 excavator, currently positioned in Zhejiang Jinhua and ready for immediate fleet deployment. Built as a joint venture/import model, this 25-ton machine delivers the reliability busy contractors demand when primary equipment is stretched thin or project timelines overlap. Traditional power architecture ensures straightforward maintenance protocols across your existing fleet, while the backhoe bucket configuration handles trenching, loading, and site preparation without specialized training requirements.

<ul>
<li>Year: 2016</li>
<li>Operating Weight: 25 tons</li>
<li>Power Type: Traditional</li>
<li>Manufacturer Origin: Joint venture/Import</li>
<li>Bucket Type: Backhoe</li>
<li>Current Location: Zhejiang Jinhua, China</li>
</ul>

For contractors managing multiple job sites or seasonal demand spikes, this SK250 serves as a proven backup solution that integrates seamlessly into existing Kobelco operations. Minimize downtime risk and maintain project momentum with equipment that matches your current fleet specifications.

Kobelco SK250

Secure proven performance without the premium price tag with this 2016 Komatsu PC120 excavator, currently located in Jieyang, Guangdong. Engineered in Japan and built to deliver consistent results, this 12-ton workhorse combines Komatsu's legendary reliability with substantial cost savings over new equipment. Powered by a robust Komatsu S4D105-5 engine producing 67.1 kW from its 4.3L displacement, this machine offers the productivity your operation demands at a fraction of new-equipment investment.

<ul>
<li>Maximum digging depth of 5,000 mm with 7,540 mm excavation radius</li>
<li>Operating weight: 11,498.6 kg with 4,600 mm boom and 2,002 mm arm</li>
<li>Efficient hydraulics: 323 L/min main pump flow for responsive performance</li>
<li>Compact footprint: 2,430 mm transport width, ideal for confined jobsites</li>
<li>70% grading ability tackles challenging terrain with confidence</li>
<li>230L fuel tank and 145L hydraulic reservoir minimize downtime</li>
</ul>

Smart contractors recognize that strategic equipment investment drives profitability. This PC120 delivers Komatsu quality and performance while preserving capital for core business growth.

Komatsu PC120

Built for high-output excavation, this 2020 Kobelco SK495D-8 delivers 49 tons of working weight and 257 kW of Hino P11C diesel power to handle large-scale earthmoving, demolition, and grading operations. With a 2.3 m³ backhoe bucket, 7-meter boom, and 11.77-meter maximum digging radius, this machine tackles deep trenching and mass excavation with precision. Dual 370 l/min hydraulic pumps provide 266 kN bucket digging force and 223 kN arm digging force, ensuring consistent performance in rocky soil and heavy material.

<ul>
<li>Maximum digging depth: 7,360 mm for utility installation and foundation work</li>
<li>Maximum digging height: 11,160 mm for loading haul trucks efficiently</li>
<li>Travel speed: 5.4 km/h for quick site repositioning</li>
<li>Climbing ability: 70% gradient capability on challenging terrain</li>
<li>Fuel capacity: 650-liter tank for extended shift operation</li>
<li>Turbocharged, intercooled engine with 1,400 N·m torque at 1,850 rpm</li>
</ul>

Currently located in Hunan, this SK495D-8 is inspection-ready and available for immediate deployment on mining, infrastructure, or commercial development projects worldwide.

Kobelco SK495D-8

Engineered with Hyundai's proven hydraulic architecture, this 2014 R225-7 excavator delivers 22 tons of precision-controlled digging force for demanding earthmoving operations. Powered by a traditional combustion engine meeting joint venture/import manufacturing standards, the R225-7 series demonstrates exceptional reliability across construction, mining, and infrastructure projects. The backhoe configuration provides optimal material handling versatility in confined work zones.

<ul>
<li>Operating weight: 22 tons with balanced load distribution</li>
<li>Hydraulic system: Advanced flow management for responsive control</li>
<li>Traditional power platform: Field-proven durability</li>
<li>Backhoe bucket: Engineered for high-volume excavation</li>
<li>Manufacturing origin: Joint venture/Import quality standards</li>
<li>Current location: Guizhou Province, China</li>
</ul>

Built during Hyundai's seventh-generation production cycle, the R225-7 incorporates refined boom geometry and strengthened undercarriage components. This unit maintains operational readiness for heavy-duty applications requiring consistent hydraulic performance and fuel efficiency. Suitable for contractors prioritizing technical reliability over speculative f

Hyundai R225-7

Built in 2015, this Komatsu PC110-7 excavator delivers proven performance backed by one of the industry's most trusted names in heavy equipment. Operating at 11 tons with a 0.48 m³ bucket capacity, this mid-size machine combines the reliability of Komatsu's SAA4D95LE-3 engine (65 kW at 2200 rpm) with hydraulic systems engineered for demanding job sites. Maximum digging depth reaches 5060 mm, while the 7730 mm working radius provides versatile coverage for earthmoving, trenching, and loading operations.

Komatsu's global parts network ensures minimal downtime—a critical advantage when purchasing used equipment. This joint venture-manufactured unit maintains strong resale value thanks to the brand's reputation for durability and long-term support. Located in Sichuan, the PC110-7 features water-cooled operation, axial piston hydraulic motors, and a 226 L/min main pump delivering consistent power across all functions.

<ul>
<li>11-ton working weight with 86 kN bucket digging force</li>
<li>Komatsu SAA4D95LE-3 engine meeting EPA/EU Tier 2 standards</li>
<li>7730 mm maximum reach, 5060 mm digging depth</li>
<li>Proven hydraulic system with 355 Mpa traveling circuit pressure</li>
<li>Global parts availability ensures long-term o

Komatsu PC110-7

Built in 2018, this Hyundai R130W wheeled excavator delivers 13 tons of proven performance backed by one of the industry's most trusted names in heavy machinery. Powered by a robust 109kW engine at 2200 rpm, this joint venture/import model combines Korean engineering standards with the parts availability and service network that make Hyundai a smart investment in the used equipment market. Currently located in Nanning, Guangxi, this machine features traditional power systems and backhoe bucket configuration ideal for urban construction, utility work, and infrastructure projects requiring mobility and versatility.

Why Hyundai Means Lower Ownership Risk:
<ul>
<li>Global parts distribution network ensures minimal downtime</li>
<li>Strong resale value retention compared to lesser-known brands</li>
<li>Proven R-series reliability with documented field performance</li>
<li>Widespread dealer support across Asia, Europe, and Americas</li>
<li>Standardized components reduce maintenance complexity and cost</li>
</ul>

Investing in established brands protects your capital. Contact Fair Trade Machinery today for full specifications, inspection reports, and competitive export pricing.

Hyundai R130W

Expand your operational capacity with this proven 2013 Komatsu PC360-7 excavator, currently located in Putian, Fujian. Built for contractors managing multiple jobsites simultaneously, this 36-ton workhorse delivers consistent performance when your primary equipment is deployed elsewhere or demand spikes beyond standard capacity.

Powered by the robust Komatsu SAA6D114E engine producing 180kW at 1900rpm, this machine handles demanding excavation tasks with authority. The 1.6m³ bucket capacity, combined with 227kN bucket digging force and 11,100mm maximum digging radius, ensures productivity across earthmoving, trenching, and site preparation applications. Water-cooled efficiency and proven hydraulic systems—featuring dual axial plunger travel motors and 535L/min main pump flow—maintain reliability during extended shifts.

<ul>
<li>Operating weight: 33,000kg with optimal 67.7kPa ground pressure</li>
<li>Maximum digging depth: 7,380mm for utility and foundation work</li>
<li>Versatile travel speeds: 3.2/4.5/5.5 km/h for efficient repositioning</li>
<li>Generous fuel capacity: 605L tank minimizes downtime</li>
<li>70% grading ability handles challenging terrain confidently</li>
</ul>

Ideal as a backup unit or fleet expans

Komatsu PC360-7

Built for precision and long-shift productivity, this 2018 Kobelco SK210-6 excavator delivers 21-ton performance with operator-first engineering. Powered by a proven traditional diesel engine, this joint venture model combines Japanese design standards with practical durability for demanding excavation work. Currently located in Jinhua, Zhejiang, the machine features a backhoe bucket configuration ready for trenching, foundation work, and material handling applications.

<ul>
<li>Year: 2018</li>
<li>Model: Kobelco SK210-6</li>
<li>Operating Weight: 21 tons</li>
<li>Power Type: Traditional diesel</li>
<li>Bucket: Backhoe configuration</li>
<li>Location: Jinhua, Zhejiang, China</li>
</ul>

Designed with enhanced cabin visibility and intuitive hydraulic controls, the SK210-6 reduces operator fatigue while maintaining smooth, responsive handling across uneven terrain. Stability systems and a well-balanced chassis ensure confident operation during high-reach tasks and precision grading. Ideal for contractors seeking reliable mid-size excavation power with proven Kobelco engineering.

Specifications	Value
No.	1038360
Tonnage (tons)	13
Working weight (kg)	13200
Bucket capacity (m³)	0.32-0.61 (0.52)
Boom length (mm)	4600
Rod length (mm)	2520
power	Traditional power
manufacturer	Made in China
bucket	backhoe
Engine type	QSF3.8
Rated power (kw/rpm)	86/2200
Cooling mode	water-cooling
Maximum torque (N.m)	470/1300
Number of cylinders (PCS)	4
Displacement (L)	3.8
Working form	Efi, Direct injection, 4-stroke, turbocharged
Ground specific pressure (Kpa)	40.4
Rotation speed (rpm)	11
Climbing ability (%)	35
Bucket digging force (kN)	99.1
Rod digging force (kN)	68
Maximum tractive force (kN)	134
Travel speed (km/h)	5.2/2.9
Maximum flow of main pump (l/min)	125.4*2
Traveling Hydraulic Circuit (Mpa)	34.4
Rotary Hydraulic Circuit (Mpa)	25
Working Hydraulic Circuit (Mpa)	31.4/34.3
Fuel Tank (L)	260
Hydraulic Tank (L)	105
Engine Oil changes (L)	11
Total transport length (mm)	7795
Total transport width (mm)	2525
Total transport height (mm)	2880
Counterweight ground clearance (mm)	931
Minimum ground clearance (mm)	466
Minimum turning radius of front working device (mm)	2445
Back end turning radius (mm)	2325
Total track length (mm)	3648
Track gauge (mm)	1990
Total track width (mm)	500
Maximum digging radius (mm)	8304
Maximum digging depth (mm)	5546
Maximum excavation height (mm)	8638
Maximum unloading height (mm)	6174
Maximum vertical digging depth (mm)	4698
Maximum effective digging depth (mm)	5335

2021 XCMG XE135D
