2022 XCMG XE15

1/7
Buy XCMG XE15 Used Excavator / 1
Buy XCMG XE15 Used Excavator / 2
Buy XCMG XE15 Used Excavator / 3
Buy XCMG XE15 Used Excavator / 4
Buy XCMG XE15 Used Excavator / 5
Buy XCMG XE15 Used Excavator / 6
Buy XCMG XE15 Used Excavator / 7

Product Description

Discover the 2022 XCMG XE15, a robust and reliable mini excavator available in Yunnan, China. This compact machine is designed for efficiency and versatility in various construction and excavation tasks. The XE15 does not come with a rake attachment but includes a standard bucket, making it ideal for small-scale digging and trenching operations. Priced at 42,000 RMB, this used model offers an excellent cost-to-performance ratio, ensuring that you get the most out of your investment. Built to meet the demands of tough job sites, the XCMG XE15 is a solid choice for contractors looking for dependable performance and ease of operation.

  • Year: 2022
  • Brand: XCMG
  • Model: XE15
  • Location: Yunnan, China
  • Price: 42,000 RMB
  • Attachments: Standard bucket (no rake)
SpecificationsValue
No.1132785
Tonnage (tons)1
Working weight (kg)1640
Bucket capacity (m³)0.044
Boom length (mm)1690
Rod length (mm)1100
Country of originXuzhou
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeYanmar 3TNV82A
Rated power (kw/rpm)16.5/2200
Cooling modewater-cooling
Number of cylinders (PCS)3
Displacement (L)1.33
Ground specific pressure (Kpa)23.8
Rotation speed (rpm)11
Climbing ability (%)30 °
Bucket digging force (kN)13.9
Rod digging force (kN)8.8
Travel speed (km/h)4.4/2.4
Main overflow set pressure (Mpa)24
Maximum flow of main pump (l/min)2*19.8+14.1
Traveling Hydraulic Circuit (Mpa)21
Rotary Hydraulic Circuit (Mpa)18
Hydraulic crushing pipeline is standardno
Main pump typeJapan Fujikoshi
Pilot pump flow (L/min)3.3
Fuel Tank (L)20
Hydraulic Tank (L)29
Engine Oil changes (L)5.5
Total transport length (mm)3760
Total transport width (mm)1080
Total transport height (mm)2400
Counterweight ground clearance (mm)472
Minimum ground clearance (mm)180
Minimum turning radius of front working device (mm)1675
Back end turning radius (mm)1190
Track gauge (mm)850
Track plate width (mm)230
Track ground length (mm)1217
Maximum digging radius (mm)3915
Maximum digging depth (mm)2320
Maximum excavation height (mm)3615
Maximum unloading height (mm)2480
Maximum vertical digging depth (mm)1520
Dodging plate width × height (mm)1080*225
