Product Description
Built for immediate deployment on demanding worksites, this 2019 XCMG XE155D crawler excavator delivers 15-ton performance across excavation, grading, and demolition applications. Powered by a QSF3.8 turbocharged engine producing 93kW at 2200rpm, this machine combines 106.9kN bucket digging force with 73.4kN arm digging force to handle heavy-duty earthmoving tasks without hesitation. Currently located in Hangzhou, Zhejiang, this China-manufactured excavator arrives ready to work with a 0.61m³ backhoe bucket, 4600mm boom, and 2520mm arm configuration optimized for versatile site operations.
- Maximum digging reach: 8304mm for extended work envelope
- Maximum digging depth: 5535mm for deep foundation and trenching work
- 260L fuel tank supports extended operating shifts
- Water-cooled engine with 500N.m maximum torque at 1300rpm
- 35% gradeability and 134kN maximum tractive force for challenging terrain
- Compact transport dimensions (7795×2590×2900mm) for easy mobilization
Equipped with electronic fuel injection and air-to-air intercooling, this XE155D provides reliable performance for contractors requiring proven excavation capacity on infrastructure, commerci
| Specifications | Value |
|---|---|
| No. | 1028290 |
| Tonnage (tons) | 15 |
| Working weight (kg) | 14600 |
| Bucket capacity (m³) | 0.32-0.71 (0.61) |
| Boom length (mm) | 4600 |
| Rod length (mm) | 2520 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | QSF3.8 |
| Rated power (kw/rpm) | 93/2200 |
| Cooling mode | water-cooling |
| Maximum torque (N.m) | 500/1300 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.8 |
| Working form | Efi, 4-stroke, turbocharged, air-to-air cold |
| Ground specific pressure (Kpa) | 37 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 35 |
| Bucket digging force (kN) | 106.9 |
| Rod digging force (kN) | 73.4 |
| Maximum tractive force (kN) | 134 |
| Travel speed (km/h) | 5.2/2.9 |
| Fuel Tank (L) | 260 |
| Hydraulic Tank (L) | 105 |
| Engine Oil changes (L) | 11 |
| Total transport length (mm) | 7795 |
| Total transport width (mm) | 2590 |
| Total transport height (mm) | 2900 |
| Counterweight ground clearance (mm) | 948 |
| Minimum ground clearance (mm) | 477 |
| Minimum turning radius of front working device (mm) | 2445 |
| Back end turning radius (mm) | 2325 |
| Total track length (mm) | 3658 |
| Track gauge (mm) | 1990 |
| Total track width (mm) | 600 |
| Maximum digging radius (mm) | 8304 |
| Maximum digging depth (mm) | 5535 |
| Maximum excavation height (mm) | 8649 |
| Maximum unloading height (mm) | 6185 |
| Maximum vertical digging depth (mm) | 4697 |
