Product Description
Available now in 河北保定, this 2016 XCMG XE18 mini excavator delivers immediate deployment without factory wait times. Powered by a reliable Yanmar 3TNV82A engine producing 16.5kW at 2200rpm, this 1.78-ton compact machine combines Japanese non-Fukoshi variable pumps with proven hydraulic systems for consistent performance on confined jobsites.
Skip the lead times and put this unit to work today. With a maximum digging depth of 2,285mm and bucket digging force of 13.9kN, the XE18 handles trenching, landscaping, and utility work efficiently. Its compact 1,300mm transport width and 1,675mm minimum turning radius enable access to restricted areas while maintaining a 30° climbing ability for challenging terrain.
- Working weight: 1,780kg with 0.044m³ bucket capacity
- Travel speed: 4.4/2.4 km/h for rapid site repositioning
- Hydraulic crushing pipeline standard-equipped
- Water-cooled 3-cylinder engine with 1.33L displacement
- Maximum digging radius: 3,915mm
- Located in 河北保定 for fast deployment to your site
Secure this ready-to-ship XCMG excavator and accelerate your project timeline with immediate availability.
| Specifications | Value |
|---|---|
| No. | 1010365 |
| Tonnage (tons) | 2 |
| Working weight (kg) | 1780 |
| Bucket capacity (m³) | 0.044 |
| Boom length (mm) | 1690 |
| Rod length (mm) | 1100 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar Yanmar 3TNV82A |
| Rated power (kw/rpm) | 16.5/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 3 |
| Displacement (L) | 1.33 |
| Ground specific pressure (Kpa) | 25.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 13.9 |
| Rod digging force (kN) | 8.8 |
| Travel speed (km/h) | 4.4/2.4 |
| Main overflow set pressure (Mpa) | 24 |
| Rotary hydraulic motor type | Plunger hydraulic motor |
| Type of walking hydraulic motor | Plunger hydraulic motor |
| Maximum flow of main pump (l/min) | 2*19.8+14.1 |
| Traveling Hydraulic Circuit (Mpa) | 21 |
| Rotary Hydraulic Circuit (Mpa) | 18 |
| Hydraulic crushing pipeline is standard | is |
| Main pump type | Japan non Fukoshi variable pump ×2+ gear pump ×1 |
| Pilot Oil Circuit (MPa) | 3.3 |
| Fuel Tank (L) | 20 |
| Hydraulic Tank (L) | 29 |
| Engine Oil changes (L) | 5.5 |
| Total transport length (mm) | 3760 |
| Total transport width (mm) | 1300 |
| Total transport height (mm) | 2405 |
| Counterweight ground clearance (mm) | 509 |
| Minimum ground clearance (mm) | 180 |
| Minimum turning radius of front working device (mm) | 1675 |
| Back end turning radius (mm) | 1190 |
| Track gauge (mm) | 1070 |
| Track plate width (mm) | 230 |
| Track ground length (mm) | 1217 |
| Maximum digging radius (mm) | 3915 |
| Maximum digging depth (mm) | 2285 |
| Maximum excavation height (mm) | 2655 |
| Maximum unloading height (mm) | 2515 |
| Maximum vertical digging depth (mm) | 1485 |
| Dodging plate width × height (mm) | 1300 x 235 |
