Product Description
Maximize your construction budget with this proven 2016 XCMG XE18 compact excavator from Guangxi Yulin. At 1.78 tons operating weight, this machine delivers exceptional value compared to new equipment pricing while maintaining robust performance capabilities.
Powered by a reliable Yanmar 3TNV82A engine producing 16.5kW, this excavator combines efficiency with durability. Key specifications include:
- Maximum digging depth: 2,285mm with 13.9kN bucket digging force
- Compact footprint: 3,760mm transport length, 1,300mm width
- Versatile reach: 3,915mm maximum digging radius
- Dual-speed travel: 4.4/2.4 km/h for optimal site mobility
- Advanced hydraulics: Japanese variable pump system with 24MPa pressure
Built in Xuzhou with proven engineering, this XE18 offers the perfect balance of maneuverability and power for tight jobsites. Smart buyers recognize the substantial cost savings versus new machinery while securing reliable performance for years of productive service. Ideal for landscaping, utility work, and small construction projects requiring precision operation.
| Specifications | Value |
|---|---|
| No. | 991312 |
| Tonnage (tons) | 2 |
| Working weight (kg) | 1780 |
| Bucket capacity (m³) | 0.044 |
| Boom length (mm) | 1690 |
| Rod length (mm) | 1100 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar Yanmar 3TNV82A |
| Rated power (kw/rpm) | 16.5/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 3 |
| Displacement (L) | 1.33 |
| Ground specific pressure (Kpa) | 25.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 13.9 |
| Rod digging force (kN) | 8.8 |
| Travel speed (km/h) | 4.4/2.4 |
| Main overflow set pressure (Mpa) | 24 |
| Rotary hydraulic motor type | Plunger hydraulic motor |
| Type of walking hydraulic motor | Plunger hydraulic motor |
| Maximum flow of main pump (l/min) | 2*19.8+14.1 |
| Traveling Hydraulic Circuit (Mpa) | 21 |
| Rotary Hydraulic Circuit (Mpa) | 18 |
| Hydraulic crushing pipeline is standard | is |
| Main pump type | Japan non Fukoshi variable pump ×2+ gear pump ×1 |
| Pilot Oil Circuit (MPa) | 3.3 |
| Fuel Tank (L) | 20 |
| Hydraulic Tank (L) | 29 |
| Engine Oil changes (L) | 5.5 |
| Total transport length (mm) | 3760 |
| Total transport width (mm) | 1300 |
| Total transport height (mm) | 2405 |
| Counterweight ground clearance (mm) | 509 |
| Minimum ground clearance (mm) | 180 |
| Minimum turning radius of front working device (mm) | 1675 |
| Back end turning radius (mm) | 1190 |
| Track gauge (mm) | 1070 |
| Track plate width (mm) | 230 |
| Track ground length (mm) | 1217 |
| Maximum digging radius (mm) | 3915 |
| Maximum digging depth (mm) | 2285 |
| Maximum excavation height (mm) | 2655 |
| Maximum unloading height (mm) | 2515 |
| Maximum vertical digging depth (mm) | 1485 |
| Dodging plate width × height (mm) | 1300 x 235 |
