Product Description
Available now in Guizhou, this 2021 XCMG XE18 mini excavator delivers immediate deployment without factory wait times. Powered by a reliable Yanmar 3TNV82A engine producing 16.5kW at 2200rpm, this 1.78-ton compact machine combines Japanese Nachi Fujikoshi variable pumps with proven hydraulic systems for responsive performance on confined jobsites.
Skip the lead times and put this versatile unit to work immediately. With a 3915mm maximum digging radius and 2285mm digging depth, the XE18 handles trenching, landscaping, and utility work efficiently. Its compact 1300mm transport width and 1675mm minimum turning radius enable access to restricted areas while maintaining a robust 13.9kN bucket digging force.
- Working weight: 1780kg with 0.044m³ bucket capacity
- Dual plunger hydraulic motors for travel and rotation
- 30° climbing ability with 25.3kPa ground pressure
- Water-cooled 3-cylinder engine, 1.33L displacement
- Standard hydraulic crushing pipeline included
- Fast deployment: Ready for immediate site delivery in Guizhou
Secure this ready-to-ship unit today and accelerate your project timeline with proven XCMG engineering.
| Specifications | Value |
|---|---|
| No. | 1007455 |
| Tonnage (tons) | 2 |
| Working weight (kg) | 1780 |
| Bucket capacity (m³) | 0.044 |
| Boom length (mm) | 1690 |
| Rod length (mm) | 1100 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar Yanmar 3TNV82A |
| Rated power (kw/rpm) | 16.5/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 3 |
| Displacement (L) | 1.33 |
| Ground specific pressure (Kpa) | 25.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 13.9 |
| Rod digging force (kN) | 8.8 |
| Travel speed (km/h) | 4.4/2.4 |
| Main overflow set pressure (Mpa) | 24 |
| Rotary hydraulic motor type | Plunger hydraulic motor |
| Type of walking hydraulic motor | Plunger hydraulic motor |
| Maximum flow of main pump (l/min) | 2*19.8+14.1 |
| Traveling Hydraulic Circuit (Mpa) | 21 |
| Rotary Hydraulic Circuit (Mpa) | 18 |
| Hydraulic crushing pipeline is standard | is |
| Main pump type | Japan non Fukoshi variable pump ×2+ gear pump ×1 |
| Pilot Oil Circuit (MPa) | 3.3 |
| Fuel Tank (L) | 20 |
| Hydraulic Tank (L) | 29 |
| Engine Oil changes (L) | 5.5 |
| Total transport length (mm) | 3760 |
| Total transport width (mm) | 1300 |
| Total transport height (mm) | 2405 |
| Counterweight ground clearance (mm) | 509 |
| Minimum ground clearance (mm) | 180 |
| Minimum turning radius of front working device (mm) | 1675 |
| Back end turning radius (mm) | 1190 |
| Track gauge (mm) | 1070 |
| Track plate width (mm) | 230 |
| Track ground length (mm) | 1217 |
| Maximum digging radius (mm) | 3915 |
| Maximum digging depth (mm) | 2285 |
| Maximum excavation height (mm) | 2655 |
| Maximum unloading height (mm) | 2515 |
| Maximum vertical digging depth (mm) | 1485 |
| Dodging plate width × height (mm) | 1300 x 235 |
