Product Description
Expand your operational capacity with this 2021 XCMG XE18 mini excavator, purpose-built for contractors requiring reliable backup equipment or cost-effective fleet expansion. Weighing just 1,780 kg with a compact 1,300 mm transport width, this machine maneuvers through restricted urban sites, residential developments, and utility trenches where larger equipment cannot operate efficiently.
Powered by a Yanmar 3TNV82A engine delivering 16.5 kW at 2,200 rpm, the XE18 provides consistent hydraulic performance across dual 19.8 l/min variable pumps. Maximum digging depth reaches 2,285 mm with a 3,915 mm working radius, while 13.9 kN bucket digging force handles compacted soil and light demolition tasks. The plunger hydraulic motor rotation system enables precise 360-degree positioning in confined spaces.
Key Fleet Integration Benefits:
- Low 25.3 kPa ground pressure protects finished surfaces and landscaping
- Standard hydraulic crushing pipeline accepts attachments without modification
- 4.4 km/h travel speed reduces repositioning downtime between job phases
- 30° climbing ability maintains productivity on sloped terrain
- Xuzhou-manufactured components ensure parts
| Specifications | Value |
|---|---|
| No. | 1016760 |
| Tonnage (tons) | 2 |
| Working weight (kg) | 1780 |
| Bucket capacity (m³) | 0.044 |
| Boom length (mm) | 1690 |
| Rod length (mm) | 1100 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar Yanmar 3TNV82A |
| Rated power (kw/rpm) | 16.5/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 3 |
| Displacement (L) | 1.33 |
| Ground specific pressure (Kpa) | 25.3 |
| Rotation speed (rpm) | 11 |
| Climbing ability (%) | 30 ° |
| Bucket digging force (kN) | 13.9 |
| Rod digging force (kN) | 8.8 |
| Travel speed (km/h) | 4.4/2.4 |
| Main overflow set pressure (Mpa) | 24 |
| Rotary hydraulic motor type | Plunger hydraulic motor |
| Type of walking hydraulic motor | Plunger hydraulic motor |
| Maximum flow of main pump (l/min) | 2*19.8+14.1 |
| Traveling Hydraulic Circuit (Mpa) | 21 |
| Rotary Hydraulic Circuit (Mpa) | 18 |
| Hydraulic crushing pipeline is standard | is |
| Main pump type | Japan non Fukoshi variable pump ×2+ gear pump ×1 |
| Pilot Oil Circuit (MPa) | 3.3 |
| Fuel Tank (L) | 20 |
| Hydraulic Tank (L) | 29 |
| Engine Oil changes (L) | 5.5 |
| Total transport length (mm) | 3760 |
| Total transport width (mm) | 1300 |
| Total transport height (mm) | 2405 |
| Counterweight ground clearance (mm) | 509 |
| Minimum ground clearance (mm) | 180 |
| Minimum turning radius of front working device (mm) | 1675 |
| Back end turning radius (mm) | 1190 |
| Track gauge (mm) | 1070 |
| Track plate width (mm) | 230 |
| Track ground length (mm) | 1217 |
| Maximum digging radius (mm) | 3915 |
| Maximum digging depth (mm) | 2285 |
| Maximum excavation height (mm) | 2655 |
| Maximum unloading height (mm) | 2515 |
| Maximum vertical digging depth (mm) | 1485 |
| Dodging plate width × height (mm) | 1300 x 235 |
